2.1 GETTING STARTED

Connect all the devices to construct a surveillance system.
1. Install HDD:
The HDD must be installed before the DVR is turned on. Please refer to Appendix #1 for HDD installation instructions.
2. Connect cameras, monitors and external devices. Please refer to the section "1.3 REAR PANEL" for connection, and
Appendix#2 for pin configurations of the external I/O port.
$
3. Connect the AC power cord to power adapter and plug into an electrical outlet.
The " " or "Power" LED will be on as red.
Press the " " or "Power" button. The "
It takes approximately 10 to 15 seconds to boot the system.
4. Set the date and time on your DVR. Please DO NOT change the date or time on your DVR after the recording function
is activated. The recorded data will be disordered and you will not be able to find the recorded data to backup by time
search.
%

2.2 SYSTEM TIME SETUP

Go to "MENU" mode, move the cursor to "DATE", and press "ENTER". The screen will show the following options.
Please DO NOT change the date or time when the recording function is activated. See "2.1 GETTING STARTED" at P.6
for details.
Set the start time and end time, and adjust the daylight saving time in hour. The above example means during the
daylight-saving time period (starting from the 4th Sunday of March and ending on the 4th Sunday of October), the system
time will plus one hour.
Downloaded from www.Manualslib.com
!
" or "Power" LED will be on as green.
3
MENU
RECORD DATE
TIMER FORMAT
DATE DAYLIGHT SAVING
ADVANCE
START
END
ADJUST
manuals search engine
0
DATE
2006 – DEC - 01 12 : 15 : 30
Y - M - D
ON
DAYLIGHT SAVING
TH
4 -SUN-MAR 24:00:00
TH
4 -SUN-OCT 24:00:00
01:00
