List Of Parts And Accessories; Usage Guide - Cvtech Winny Compact 16 Bedienungsanleitung

5.
(21)
(13)
(16)
(19)
(18)
(20)
1. Insert the Power Supply cord(2) and turn on the Power Supply switch (1). The "Power" in-
dicator light will stay lit, indicating that the central vacuum unit is receiving power supply. The
central vacuum unit is now ready for use. This appliance leaves the factory ready for use. It
2. In order to prepare the hose connect the end to the wand and the appropriate brush for the
type of surface you are going to vacuum.
3. Introduce the other end of the hose in the closest vacuum inlet valve. When you introduce
14
INSTRUCTIONS MANUAL WINNY COMPACT 16
11
(12)
(17)
(15)
(14)
1. POWER SUPPLY SWITCH
2. POWER SUPPLY CABLE AND PLUG
3. AIR INLET
4. INFORMATION PANEL
5. MOTOR
6. REMOVABLE FILTER
7. CYCLONE FUNNEL
8. EXHAUST MUFFLER
9. DUST CONTAINER
10.OPENING CONTAINER HANDLES
11. AIR OUTLET
12. SCHLAUCH
13. SCHLAUCHHALTER
14. SAUGROHRE
15. ZUBEHÖRTASCHE
16. KOMBIDÜSE
17. BÜRSTENDÜSE
18. FUGENDÜSE
19. MÖBELDÜSE
20. POLSTERDÜSE
21. HALTER
