BERG Compact
A A
A
A
1
1a 1b
X=Y-5mm
B
B
B

2.2.4 Driving mechanism

2.2.4.1 Chain
2
The product has a driving mechanism with two chains. Make sure that the chains are sufficiently oiled
so that they can travel freely. If a chain is too tightly tensioned, the gokart will be more difficult to pedal
and there is a big chance that wear and tear of the chains and sprocket, among other things, will occur
faster. If a chain is not tight enough, then the chain can easily come off the sprocket, or there is a chance
of damage to the chain housing. When both chains must be tensioned, always begin with the rear/short
chain.
Tensioning the front chain:
• Loosen the bolts on the underside of the frame.
• Tension the chain by moving the crank axle forwards.
• Tighten the bolts again.
• It must be possible to push the middle of the chain downwards by 10 millimeters. To check this you
must remove the lower half of the chain housing.
1
2
16
