Samlevejledning - Assembly Instructions - Montageanleitung - Instructions d'assemblage - Instrucciones de montaje
0030
H: 16,0cm
Coll.1 - 0030
A x 4
004176
E x 4
004314
N x 2
004307
943780030 - 16-04-2015/ 3
Bed Concept
Design by BoConcept
B x 6
D x 8
004175
004300
F x 4
004302
P x 2
004308
C x 20
L x 16
970000749
970000883
5.ox25mm
M8
J x 44
G x 12
1978890002
970000903
D18x1.25mm
M8x45mm
K x 32
Q x 6
9799000119
970000685
M8x15mm
M6x50mm
R x 1
1979300004
4mm
H x 1
1979300005
5mm
M x 1
979900048
12mm
1 /3
