EN
4
550GC Series Cycle Part List
Open the shipping carton. Remove all parts from the carton and cardboard inserts.
Before you begin assembly, verify that the following hardware items are packed with the equipment. You will require the following
to assemble the 550GC Series: 1* 2.5, 3, 5, 6 and 15mm hex wrench, and a Phillips screwdriver.
1. 2.5, 3, 5, 6, hex wrenchs, 15mm wrench and
(NOT INCLUDED)
Phillips screwdriver
4. Cover, Stabiliser, front
QTY 1
7. Dipping, handlebar, rear
QTY 1
2. Stabliser, front, assy
QTY 1
5. Cover, Stabiliser, rear
QTY 1
8. Dipping, handlebar, front for GC
QTY 1
Intenza 550GC Series Cycle Handbook: 550GC Series Cycle Part List
3. Stabliser, rear, assy
QTY 1
6. Cap, end, track, HB, rear
QTY 1
9. Assy, frame, main
QTY 1
