EN: Installation Instructions
Legend for Figures
1 Magnetic contact
2 Installation and connection diagram
A Contact
B Magnet
3 Distance diagram
A Proximity/switch-on distance
B Distance/switch-off clearance
C Tolerance zone
D Contact
E Magnet
4 Connection
A, B, C, D Connection cable
Note: B and D are the 2 twisted cables for the tamper loop.
E Switching part (NC)
F Tamper protection (internal reed)
G EOL resistor
Description
The magnetic contact and the magnet must be mounted facing
each other in a window frame/door leaf and window
surround/door surround.
Caution: Neither the contact nor the magnet can be installed in
ferromagnetic materials.
Special grade 3 magnetic contacts developed for installation in
ferromagnetic materials are available for this case.
The installation flange must only be mounted using screws made
of non-magnetic material.
When mounting is complete, the magnetic contact's electrical
switching function must be checked (e.g. using a continuity tester
or multimeter).
The application of mechanical force, e.g., when mounting the
device on the casing may damage the glass body of the reed
switch.
Only cyanacrylate adhesives (superglue) may be used to fix the
assembly parts. The processing instructions from the respective
manufacturer must be observed.
Caution: Measure the supply lines electrically before connecting
them!
Distance Diagram
See Figure 3.
Minimum switch-on distance:
tolerance in x:
Table 2
Proximity/switch-on distance
Distance/switch-off clearance
2 of 9
11 mm,
max. +/- 3 mm
Switch-on Tolerance
distance [mm] [mm]
15 +/- 4
20 +/- 4
Technical Data
Flush-mounted magnetic contact DC128 for EOL zone types,
tamper protected.
Note: Only front flush and surface-mounting possible.
Contact type 1 - pin NC contact
Switching distance 15 mm, +/- 4 mm
Switching voltage max. 100 V DC
Switching current max. 500 mA
Contact rating max. 6 W or 6 VA
Contact resistance max. 0.15 Ohm
Breakdown voltage > 250 V
Permissible operating max. 40 V
voltage
Connection cable LIYY 4 x 0.14 mm Cu tin-plated;
Suitable for LSA IDC method of termination
External cable color White
Internal conductor Blue (yellow pattern)
∅ 8 x 32 mm
Contact dimensions
∅ 3.2 mm x 2 m (DC128)
Cable dimensions
∅ 3.2 mm x 6 m (DC128S60)
∅ 6 x 19 mm neodymium, axially polarized,
Magnet
in ∅ 8 x 25 mm plastic sleeve
Housing material S-B or A-B-S
Color White
Temperature range - 25 °C to + 70 °C
Protection category VdS - environmental class III, IP 67
Scope of Delivery
• 1 magnetic contact ∅ 8 x 32 mm
• 1 magnet 6 x 19 mm neodymium in plastic sleeve
∅
8 x 25 mm
∅
• 2 installation flange EF 8/10 for wood, plastic and non-
magnetic metals
• 4 fastening screws DIN 7982 - 2.9 x 13 - V 2 A
European Directive
Tested & Certified
EN EN 50131-2-6 Grade 3 by VdS
VdS no. G110010 (Cl. C)
European GE Security B.V., Kelvinstraat 7, 6003 DH Weert,
Representative of The Netherlands.
Supplier
The goal of the EC directive on waste electrical and
electronic equipment is to minimize the
environmental and health impact of such
equipment. In accordance with this directive,
electrical devices bearing this symbol must not be
disposed of in the European public waste disposal
systems. European users of electrical devices must
now return all waste electrical and electronic
equipment for recycling. For more information,
please visit: www.recyclethis.info
