Hi-Speed USB 2.0 Gigabit Ethernet Adapter • User Manual
Thank you for purchasing the INTELLINET NETWORK SOLUTIONS
Gigabit Ethernet Adapter, Model 505932.
Package Contents
• Hi-Speed USB 2.0 Gigabit Ethernet Adapter
• USB cable (1.5 m / 5 ft., type A to type B)
• Setup CD
• User manual
Indicators and Ports
LED Status
Power On
Link/Act On
Blinking Receiving packets
USB On
480 Mbps Off
10/100/ On
1000 Blinking Connected at 100 Mbps
Off

Hardware Installation

1. Use the included USB cable to connect the USB port on the adapter to a USB port on
your computer.
2. Using Cat6 Ethernet cable, connect the RJ45 port of the adapter to a Gigabit Ethernet
port on your router, switch or other networking device.
Driver Installation (follow Step 3 that matches your system)
1. Insert the included setup CD in your CD-ROM drive.
2. On your desktop, click "Start" then "Run. "
3. When the prompt displays
• For Windows XP (32-bit) — Enter "D:\505932_USB_Gigabit_Ethernet_Adapter\
WinXP\setup.exe" (where "D" is the designation of your CD drive).
• For Windows Vista (32/64-bit) — Enter "D:\505932_USB_Gigabit_Ethernet_Adapter\
Vista\setup.exe" (where "D" is the designation of your CD drive).
• For Windows 7 (32/64-bit) — Enter "D:\505932_USB_Gigabit_Ethernet_Adapter\
Win7\setup.exe" where "D" is the designation of your CD drive).
4. Follow the on-screen instructions to complete the software installation.
5. Restart your computer. Once you've re-booted, the adapter is ready for use.
2
ENGLISH
Downloaded from www.Manualslib.com
Description
Power is on
Valid connection is made
Operating at High Speed
Operating at Full Speed
Connected at 1000 Mbps
Connected at 10 Mbps
