SMS CASING SPECIFIC OHF FREESTAND
6
LIST OF PARTS (continued)
For SMS Casing Specific OH46F/OH55F Landscape Basic only
C1 (1x)
S1 (4x)
Display screw
SCREW LIST
S1
Screw M8x16
S2
Screw M6x16
S3
Screw M6x40
S4
Screw M6x8
S2 (6x)
Safety screw
4x
6x
8x
4x
D1 (2x)
S3 (8x)
Safety screw
Safety screw
S4 (4x)
