09 109 2097 AA4200 Adjustable Padded Leg Rest
Please read these instructions carefully and retain for future reference
Safety
Do not sit or stand on the Leg Rest, the product is not
intended to support full body weight.
Installation and Adjustment
These products are supplied flat-packed and are simple to
assemble or dis-assemble again without tools, using the
instructions opposite:
1. Adjust the legs attached to the padded seat to an angle
of 60° by releasing the triangular knob.
2. Remove the two pin clips from the base legs.
3. Slide the leg assembly over the legs attached to the seat.
Adjust the legs to the required position and clip through
the holes with the pins provided.
Manufactured for: Patterson Medical Ltd, Nunn Brook Road, Huthwaite,
Sutton-in-Ashfield, Nottinghamshire, NG17 2HU, UK.
UK: Tel: 08444 124 330 Fax: 08448 730 1000 www.homecraft-rolyan.com
International: Tel: +44 1623 448 706 Fax: +44 1623 448 784
Patterson Medical Inc. 1000 Remington Blvd., Suite 210, Bolingbrook, IL 60440-5117, USA.
Tel: 1-800-323-5547 Telefax: 1-800-547-4333
70038 Is6 © Patterson Medical Ltd. 2012
4. Angle the padded top to the desired angle and fasten
the triangular knob to lock in position.
5. To disassemble, reverse the procedure.
Cleaning and Care
All metal parts may be cleaned using a brush or
a cloth, and a solution of mild detergent and
disinfectant (e.g. Dettox).
