axing AVM 3-00 Betriebsanleitung Seite 3

Safety advices:
 Installation and repairs to the device must be carried out exclusively by
a specialist in accordance with the applicable guidelines. No liability is
assumed for faulty installation and commissioning.
 Before handling the device, disconnect the power supply, otherwise there
is danger to life. This also applies if you clean the device or work on the
connections.
 Use only the plug-in power supply unit included in the delivery scope!
By no means is it allowed to replace any parts of the power supply unit
or to make modifications. Otherwise, there is a risk of mortal injury for
which we cannot be held liable.
 Providing that a serviceable fuse exists, the power cord must be pulled
out before changing the fuse. Defective fuses may only be replaced with
standard compliant fuses that have the same nominal value.
 The equipment may only be operated in dry rooms. In humid rooms or
outdoors there is danger of short-circuit (caution: risk of fire) or electro-
cution.
 The mains plug is used as a disconnecting device from the mains voltage
both during service and in case of danger and must therefore be reacha-
ble and usable at all times. After connection to the mains, the power
supply is in operation.
 Choose the location of installation or mounting such that children may
not play unsupervised near the equipment and its connections. The
location of installation or mounting must allow a safe installation of all
cables connected. Power feeding cables as well as feeder lines may not
be damaged or clamped by objects of any kind. To prevent damage to
your equipment and to avoid possible peripheral damages, the devices
foreseen for wall mounting may only be installed on a flat surface.
 Choose the location of installation or mounting so that under no circum-
stances liquids or objects can get into the equipment (e.g. condensation,
water coming from leaking roofs or flowing water, etc.).
 Avoid exposure of the equipment to direct sunlight and to other heat
sources (e. g. radiators. other electrical devices, chimney, etc.). Devices
that are equipped with heat sinks or ventilation slots must under no
circum-stances be covered or blocked. Also ensure for a generous air
circulation around the equipment. In this way you avoid possible damage
to the equipment as well as a risk of fire caused by overheating. Abso-
lutely avoid that cables come near any source of heat (e.g. radioators,
other electrical devices, chimney, etc.).
 In case of damage, interrupt the power supply immediately.
 Do not try to repair the device. This device should only be serviced or
repaired by qualified service personnel. Contact your distributor for more
information.
 Do not open the device.
 For disassembly always pull the power supply first and disconnect the
power supply cable from the device.
Herewith AXING AG declares that the marked products comply with the valid
guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
State of the art 2020-05-19
Technical improvements, changes in design, printing- and other errors expected.
Technical data:
Type
RF Connectors (input)
Inputs
Video level
Video impedance
Audio level typ.
Audio impedance typ.
Connectors audio/video
Output
Through gain
Frequency range
Channels selectable
Output level adjustable
Connectors
Connector type
General
Dimensions (W × H × D) appr.
External accessories
Plug-in power supply
Commission regulation (EU) 2019/1782
External plug-in power supply
Manufacturer's name or trademark Shenzhen Greenpowerone Co LTD
commercial registration number Unit 04, 7 Fl, Bright Tower 33 Mong Kok Rd
and address
91441900MA4W0ULB9R
Model identifier
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average active efficiency
Load condition 1 – 100 % ± 2 %
Load condition 2 – 75 % ± 2 %
Load condition 3 – 50 % ± 2 %
Load condition 4 – 25 % ± 2 %
No-load power consumption
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
AVM00300
F-female
1 VSS
75 Ohm
1 VSS AVM 3-00
10 kOhm
RCA/Cinch + SCART
basic-line
2...4 dB
470...862 MHz
TWIN audio/video
PAL BG / PAL I / SECAM L
70...90 dBµV
modulator
F-female
190 x 170 x 40 mm
Operation instructions
100...240 V~/50...60 Hz/3 W |
6 V=/500 mA
Kowloon, Hong Kong
GA01-0600500EU
100...240 V
50...60 Hz
6,0 V
0,5 A
3,0 W
76,6 %
76,5 %
76,4 %
74,3 %
0,06 W
