How To Use; Technical Specifications - Inateck FD1008 Bedienungsanleitung

How to Use

1. Connect the external power adapter from the hard drive dock to an electrical outlet.
2. Connect the included USB 3.0 cable from the hard drive dock to an available USB port
on the computer system.
3. Insert a 2.5" or 3.5" hard drive into the top loading slot.
4. Press the power button. A pop-up bubble in the task bar at the bottom-right of your
screen notifying you once your hard drive has been recognized. You may also find the
hard drive in Disk Management.
Note:
a. To remove the hard drive, make sure it is currently not being accessed by the computer
then unmount or uninstall the disk drive from the operating system. Never remove the
docking station while the hard drive is in use. Doing so may corrupt the data on the
hard drive or damage the hard drive, docking station, or computer.
b. When connected via USB, the dock will automatically go into sleep mode if the
connection is left idle for more than 30 minutes. The power LED indicator will flash
every 3 seconds. Accessing the hard drive will automatically cancel sleep mode and
power the drive back up. The hard drive LED indicator will flash and the power LED
indicator will be constantly on.

Technical Specifications

Product Name
Model Number
Weight
Color
Drive Size
Interface
Material
Hot Plug, Plug & Play
Licenses
Dimensions
Environmental
Operating Systems
USB3.0 SATA HDD/SSD Docking Station
Inateck FD1008
307g
Black
2.5"/3.5" SATA I/II/III HDD/SSD
USB3.0 - Up to 5Gbps
ABS plastic
Supported
CE, FCC
156mm length × 63mm width × 68mm height
Storage: -20 to 70 ° C; Operating: 5 to 40 ° C
Windows XP/7/8/8.1/10, Mac OS 9.0 and higher
