- Seite 1 UniFi Protect ViewPort Model: UFP-VIEWPORT...
-
Seite 2: Package Contents
Package Contents UniFi Protect Mounting Double-Sided HDMI Cable ViewPort Bracket Tape M6 Screw M8 Screw Drywall Screws Screw Anchors (Qty. 2) (Qty. 2) System Requirements • UniFi Protect software TBD v1.X or above, available at ui.com/downloads/unifi Installation Requirements • Phillips screwdriver •... -
Seite 3: Hardware Overview
Hardware Overview Power/Status LED Color Status Solid White Ready for configuration. The device has been adopted by the UniFi Blue Protect Controller. Alternating Blue/White The device is booting up. Main Port This 10/100/1000 RJ45 port connects to an 802.3af switch for PoE power and data. - Seite 4 HDMI Port This HDMI port connects to a TV or monitor with an HDMI cable. It supports 1080p and 4K displays. Secondary Port This 10/100/1000 RJ45 port functions as a data pass-through port. Reset Button Restore to Factory Defaults Press and hold the Reset button for 5 seconds while the device is powered on.
-
Seite 5: Hardware Installation
Hardware Installation Mounting the UniFi Protect ViewPort is optional; it allows the device to be installed in an inconspicuous and safe location. You have three options for mounting: Wall Mount • Mount the ViewPort onto a drywall surface. • TV VESA Mount Mount the ViewPort to the back of your TV/monitor using the available VESA mounting hole(s). - Seite 8 TV VESA Mount You can use this option if your TV or monitor is equipped with a VESA mount that uses M6 or M8 screws. 1. Optional (for permanent mounting) M8 Screw M6 Screw...
- Seite 9 M8 Screw M6 Screw...
- Seite 10 TV Surface Mount...
- Seite 12 Connecting the ViewPort WARNING: The switch port must comply with the power specifications listed in “Specifications”. Note: The PoE switch must be connected to the same LAN or VLAN as the UniFi Protect controller.
- Seite 13 4. Follow the instructions on the TV or monitor. (If nothing is displayed, check the power source to the device.)
- Seite 14 5. Log in to UniFi Protect. Enter the UniFi Protect username and password. Then click Submit. 6. When UniFi Protect detects the ViewPort, click Add Device.
-
Seite 15: Specifications
Specifications UFP-VIEWPORT Dimensions (With TV Mount) 156.9 x 52 x 37.35 mm (6.18 x 2.0 x 1.47") Weight Without TV Mount 230 g (8.11oz) With TV Mount 252 g (8.89 oz) Enclosure Polycarbonate Networking Interface 10/100/1000 Ethernet Port Management Interface UniFi Protect Controller Max. -
Seite 16: Safety Notices
Safety Notices 1. Read, follow, and keep these instructions. 2. Heed all warnings. 3. Only use attachments/accessories specified by the manufacturer. WARNING: Do not use this product in a location that can be submerged by water. WARNING: Avoid using this product during an electrical storm. -
Seite 17: Important Note
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •... -
Seite 18: Avis Important
AVIS IMPORTANT : Déclaration sur l’exposition aux rayonnements : • Cet équipement est conforme aux limites prévues pour l’exposition aux rayonnements dans un environnement non contrôlé. • Lors de l’installation et de la mise en fonctionnement de l’équipement, assurez-vous qu’il y ait une distance minimale de 20 cm entre l’élément rayonnant et vous. - Seite 19 Deutsch Die Europäische Richtlinie 2012/19/EU verlangt, dass technische Ausrüstung, die direkt am Gerät und/oder an der Verpackung mit diesem Symbol versehen ist, nicht zusammen mit unsortiertem Gemeindeabfall entsorgt werden darf. Das Symbol weist darauf hin, dass das Produkt von regulärem Haushaltmüll getrennt entsorgt werden sollte. Es liegt in Ihrer Verantwortung, dieses Gerät und andere elektrische und elektronische Geräte über die dafür zuständigen und von der Regierung oder örtlichen Behörden dazu bestimmten Sammelstellen zu...
-
Seite 20: Declaration Of Conformity
English Hereby, UBIQUITI, declares that this UFP-VIEWPORT device, is in compliance with the essential requirements and other relevant provisions of Directives 2014/53/EU, 2014/30/EU, 2014/35/EU. The full text of the EU declaration of conformity is available at the following internet address: ui.com/compliance... - Seite 21 Az EU-megfelelőségi nyilatkozat teljes szövege elérhető a következő internetes címen: ui.com/compliance Íslenska [Icelandic] Hér, UBIQUITI, því yfir að þetta UFP-VIEWPORT tæki er í samræmi við grunnkröfur og önnur viðeigandi ákvæði tilskipana 2014/53/ESB, 2014/30/ESB, 2014/35/ESB. Fullur texti ESB samræmisyfirlýsing er að finna á eftirfarandi netfangi: ui.com/compliance...
-
Seite 22: Online Resources
©2019 Ubiquiti Inc. All rights reserved. All rights reserved. Ubiquiti, Ubiquiti Networks, the Ubiquiti U logo, the Ubiquiti beam logo, UniFi, and UniFi Protect are trademarks or registered trademarks of Ubiquiti Inc. in the United States and in other countries. All other trademarks are the property of their respective owners.
