Whispbar K781W Montageanleitung Seite 73

Fitting Kit
Insignia, 4dr Sedan Oct 08-+ (AU)
Insignia, 4dr Sedan Oct 08-+ (EU)
Insignia, 4dr Sedan Oct 08-+ (CN)
Insignia, 5dr Hatch 09-+ (EU)
Insignia, 5dr Hatch 09-+ (CN)
A B
-415mm 280mm
-16 -5/16ths" 11"
-415mm 280mm
-16 -5/16ths" 11"
-415mm 280mm
-16 -5/16ths" 11"
-415mm 280mm
-16 -5/16ths" 11"
-415mm 280mm
-16 -5/16ths" 11"
73
C 1
- 910mm
- 35 13/16ths"
- 910mm
- 35 13/16ths"
- 910mm
- 35 13/16ths"
- 905mm
- 35 5/8ths"
- 905mm
- 35 5/8ths"
K781W
X
2 3
860mm -
33 7/8ths" -
860mm -
33 7/8ths" -
860mm -
33 7/8ths" -
850mm -
33 7/16ths" -
850mm -
33 7/16ths" -
