Heimsport-Trainingsgerät Elektrisches Laufband LB 50+ Montage- und Bedienungsanleitung für Assembly and exercise instructions for Bestell-Nr. 1350 Order No. 1350 Notice de montage et d’utilisation du Montage- en bedieningshandleiding voor No. de commande 1350 Bestellnummer 1350 Инструкция по монтажу и эксплуатации №...
Inhaltsübersicht Contents Page 1. Wichtige Empfehlungen und Sicherheitshinweise Seite 2. Einzelteileübersicht Seite 3. Technische Daten Seite 4 - 5 Sommaire Page 4. Montageanleitung mit Explosionsdarstellungen Seite 6 - 7 5. Wartung und Einstellung Seite 7. Computeranleitung Seite 8. Trainingsanleitung Seite 10 Inhoudsopgave Pagina 27 Sehr geehrte Kundin, sehr geehrter Kunde...
Seite 4
Telefon: +49 (0) 20 51 / 60 67-0 • Geschwindigkeit: 0,8 km/h bis 10 km/h (in 0,1 km/h Telefax: +49 (0) 20 51 / 60 67-44 Schritten einstellbar) e-mail: info@christopeit-sport.com • Schwingungsgedämpfte Lauffläche www. christopeit-sport.com • Sicherheitsbandstopp • Platz sparend hochklappbar Dieses Laufband ist nur für den privaten Heimsportbereich...
Seite 6
Montageanleitung Bevor Sie mit der Montage beginnen, unbedingt unsere Emp- fehlungen und Sicherheitshinweise beachten! Schritt 1: Montagevorbereitung 1. Entnehmen Sie alle Einzelteile aus dem Karton und legen Sie den vormontierten Grundkörper mit Unterstützung einer zwei- ten Person auf den Boden. Schritt 2: Montage der Stützrohre links und rechts (2+3) am Grundrah- men (4).
Seite 7
Schritt 4: Kontrolle und Inbetriebnahme 1. Alle Verschraubungen und Steckverbindungen auf ordnungs- gemäße Montage und Funktion prüfen. 2. Wenn alles soweit in Ordnung ist, stecken Sie das Netzkabel (52) in eine vorschriftsmäßig installierte Steckdose (220-240V~50- 60Hz) ein und schalten Sie den Hauptschalter (17) unten, vorne am Grundgerät ein.
Anmerkungen zur Wartung und Einstellung 1. Pflegen der Lauffläche: Damit das Laufband dauerhaft leicht und gut läuft, sollte immer nach 50 Betriebsstunden die Unterseite der Lauffläche, welche auf dem Gleitbrett liegt auf Ihre Gleitfähigkeit geprüft werden und ggf. mit Siliconspay (Kein Schmierstoff auf ÖL- oder Petroleum Basisverwenden) nachbehandelt werden.
Seite 9
Computerbeschreibung für Art.-Nr. 1350 Zeit: Zeigt an wie lange Sie gelaufen sind. (0:00 - 99:59Min.) Bei Erreichen des Wertes 99:59Min stoppt das Laufband automa- tisch. Tasten: Start -Taste Durch Drücken dieser Taste startet das Laufband und die Laufflä- che läuft 3 Sekunden verzögert an. Stopp -Taste Durch Drücken dieser Taste stoppt das Laufband und die Laufflä- che hält etwas verzögert an.
Minuten lang, Dehnungsübungen und/oder leichte gymnastische Übungen durchgeführt werden. Weitere Informationen zum Thema Aufwärmübungen, Dehnungsübungen oder allgemeine Gymnastikübungen finden Sie in unserem Downloadbereich unter www.christopeit-sport.com Garantiebestimmungen gemäße Behandlung, Gewaltanwendung und Eingriffen die ohne vorherige Absprache mit unserer Service Abteilung vorgenommen werden, erlischt die Garantie.
Seite 11
Contents 1. Summary of Parts Page 2. Important Recommendations and Safety Information Page 11 3. Technical data Page 12 - 13 4. Assembly Instructions With Exploded Diagrams Page 14 - 15 5. Maintenance and adjusting Page 16 6. Console Key pad functions Page 17 7.
Telefon: +49 (0) 20 51 / 60 67-0 • Speed from 0,8 km/h - 10 km/h Telefax: +49 (0) 20 51 / 60 67-44 (adjustable in 0,1 km/h steps) e-mail: info@christopeit-sport.com • Vibration absorbing running surface www. christopeit-sport.com • Safety pin for emergency stop •...
Seite 13
Illustration Designation Dimension mm Quantity Attached to ET-Number Illustration No. Round cap 36-1350-21-BT Hand grip foam 36-1350-22-BT Handrail 33-1350-07-SI Handrail cover 36-1350-23-BT Connection cable 1 15+44 36-1350-24-BT 44-47 Computer 36-1350-03-BT Safety Key 36-1350-25-BT Light Sensor 36-1350-26-BT Screw 4x12 39-10188 Screw M5x8 39-9903 AC power cable...
Seite 14
Assembly Instructions Before beginning assembly, be sure to observe our recom- mendations and safety instructions. Step 1: Preparing for Assembling 1. Put all parts out of carton and place the preassembled main frame (1) with bottom frame (4) on the floor with help from a second person.
Seite 15
Step 4: Checks and how to start. 1. Check the correct installation and function of all screwed and plug connections. 2. When everything is in order, connect the power supply cable (52) with wall power (220-240V~50-60Hz) and switch on the main switch (17) below the front frame.
Maintenance and adjusting 1. Lubrication for the running belt: In order to keep the machine in the best condition, please add some Silicone oil between the running belt and the running board after 50 hours or 1 to 2 month of use. But the running belt may slip, if you lubricate too much.
Seite 17
USER MANUAL OF COMPUTER 1350 Time: Shows the time of exercising. (0:00 - 99:59Min.) After reach value of 99:59Min the treadmill stops automatically. Keys: Start -key Press this key to start the treadmill and after a countdown of 3 sec. the running surface start move.
/ or light gymnastic exercises for a period of five to ten minutes. You find further information on the subject warm-up exercises, stretch exercises or general gymnastics exercises in our download area under www.christopeit-sport.com 4. Motivation The key to a successful program is regular training. You should set a fixed time and place for each day of training and prepare yourself mentally for the training.
Seite 19
Sommaire 1. Aperçu des pièces Page 2. Recommandations importantes et règles de sécurité Page 3. Nomenclature Page 20 - 21 4. Notice de montage avec écorchés Page 22 - 23 5. Maintenance et réglages Page 6. Manuel d’utilisation du calculateur électronique Page 7.
Seite 20
• Blue Back Light LCD écran avec affichage du temps, de la Telefon: +49 (0) 20 51 / 60 67-0 Telefax: +49 (0) 20 51 / 60 67-44 vitesse, de la distance et du nombre approximatif de calories e-mail: info@christopeit-sport.com brûlées • Charge max. 100 kg www. christopeit-sport.com •...
Seite 21
Schéma Désignation Dimensions Quantité Monté sur Numéro ET n° en mm Unités schéma n° Revêtement de poignée 36-1350-22-BT Main courante 33-1350-07-SI Revêtement 36-1350-23-BT Câble d’ordinateur 1 15+44 36-1350-24-BT 44-47 Ordinateur 36-1350-03-BT Clip de sécurité 36-1350-25-BT Capteur 36-1350-26-BT 4x12 39-10188 M5x8 39-9903 Câble d’...
Instructions de montage Il est strictement conseillé d’observer nos recommandations et consignes de sécurité avant de commencer le montage ! Etape n° 1: Préparation de l’installation 1. Retirez tous les éléments de la boîte et placer le pré-corps de support d’une seconde personne sur le sol. Etape n°...
Seite 23
Etape n° 4: Contrôle et mise en marche: 1. Vérifier si les assemblages et connexions ont été effectués cor- rectement et fonctionnent. 2. Si tout est en ordre, branchez la câble d’alimentation (52) dans une prise AC (220-240V~50-60Hz) et mettez l’appareil sous in- terrupteur (17).
Maintenance et réglages : 1. Lubrification du tapis de course Afin de conserver votre appareil dans le meilleur état, veuillez ajouter un peu d’huile de silicone entre la bande de roulement et la base après 50 heures d’entraînement (entre 1 à 2 mois d’utilisation).
Seite 25
Description de l’ordinateur pour l’art.-Nr. 1350 Calories (CAL): Indique le nombre approximatif de calories brûlées en kcal (0.0 - 999 kcal.) (Base 30kcal par Km) Temps (TMR): Indique la durée de la course. (0:00 - 99:59Min.) Atteindre la valeur 99:59 min tapis roulant s‘arrête automatique- ment.
Vous trouvez les autres informations au sujet exercices pour réchauffer, aux exercices de distension ou les exercices de gymnastique généraux dans notre domaine de téléchargement sous le www.christopeit-sport.com 4. Motivation Un entraînement régulier est la clef de la réussite de votre programme.
Inhoudsopgave 1. Overzicht van de losse delen pagina 2. Belangrijke aanbevelingen en veiligheidsinstructies pagina 27 3. Technische specificatie pagina 28 - 29 4. Montagehandleiding pagina 30 - 31 6. Onderhoud en aanpassing pagina 32 7. Console tiptoets functie pagina 33 8.
Seite 28
Telefon: +49 (0) 20 51 / 60 67-0 Telefax: +49 (0) 20 51 / 60 67-44 • Blue Back Light LCD beeldscherm voor de indicatie van de e-mail: info@christopeit-sport.com tijd, de snelheid, de afstand en het calorieënverbruik onge- veer. www. christopeit-sport.com •...
Seite 30
Montagehandleiding Voordat u met de montage begint, absoluut onze adviezen en veiligheidsvoorschriften in acht nemen! Stap 1: Voorbereiden van den installatie. 1. Neem de van te voren geïnstalleerde machine uit de verpakking en plaats het base frame met behulp van twee personen op de grond.
Seite 31
Stap 4: Controle en Inbedrijfsname: 1. Alle schroef- en stekkerverbindingen op een corr.cte montage en juiste werking controleren. 2. Wanneer alles in orde is, steek de stekker de electriciteitskabel (52) in een AC contact doos (220-240V~50-60Hz) en zet de ma- chine aan door drukken van de schakelaar (17).
Seite 32
Onderhoud en aanpassing 1. Smeren van de loopband: Om de machine in goede staat te houden smeer wat Siliconenolie tussen de loopband en de loopplaat na gebruik van 50 uur of 1 tot 2 maanden. De loopband zal slippen als u teveel smeert. Om de band te smeren trek de loopband omhoog en injecteer de siliconenolie in het gat tussen de band en de loopplaat.
Seite 33
Computerbeschrijving voor Art.-Nr. 1350 Tijd: Toont de door u gelopen tijd. (0:00 - 99:59Min.) Het bereiken van de waarde 99:59 min loopband stopt automa- tisch. Toetsen: Start –Toets Wanneer u op deze knop drukt, start van de loopband gedurende 3 seconden vertraagd toe. Stop –Toets Door op deze knop stopt de loopband en het loopvlak heeft een lichte vertraging na stop.
Seite 34
Voor meer informatie over uitoefening van warme up, oefening te rekken of algemene gymnastische oefenen in onze downloadarea onder www. christopeit-sport.com 4. Motivatie De sleutel tot een succesvol programma is een regelmatige training. U kunt het beste een vaste tijd en plaats per trainingsdag vaststellen en u ook geestelijk op de training voorbereiden.
Обзор содержания Важные рекомендации и указания по безопасности стр. 2. Обзор отдельных деталей стр. 3. Технические характеристики стр. 36 - 37 4. Руководство по монтажу стр. 38 - 39 5. Ввод в эксплуатацию: стр. 6. Индикация и функции: стр. Руководство по тренировкам стр.
Seite 36
42551 Velbert • регулировка скорости с шагом 0,1 км/ч Telefon: +49 (0) 20 51 / 60 67-0 • Амортизирующая беговая поверхность Telefax: +49 (0) 20 51 / 60 67-44 • Ключ безопасности e-mail: info@christopeit-sport.com • Складная конструкция для экономии места www. christopeit-sport.com • Blue Back Light Компьютер с следующих параметров: время, скорость, дистанция, прибл. расход калорий • Максимальный вес пользователя: 100 кг Этот конвейер к только для частной области спорта дома...
Seite 37
№ Наименование Размеры в мм Кол-во Монтируется на № ЕТ-№ картинки штук Поручни 33-1350-07-SI Заглушка 36-1350-23-BT Кабель компьютера 1 15+44 36-1350-24-BT 44-47 Компьютер 36-1350-03-BT Предохрнительный клип 36-1350-25-BT Сенсор 36-1350-26-BT Болт 4x12 39-10188 Болт M5x8 39-9903 Кабель блока питания 36-1350-27-BT Болт с шестигранной головкой M8x20 1+53 39-10095-SW...
Руководство по монтажу Прежде чем начинать сборку, обязательно ознакомьтесь с рекомендациями и инструкциями по технике безопасности! Шаг 1: Подготовка к установке 1. Возьмите все детали устройства из коробки и поставить уже собрали основной корпус, имеющий второй человек на земле. Шаг 2: Монтаж...
Seite 39
Шаг 4: Управление и ввод в эксплуатацию. 1. Проверьте все соединения болтов и соединений на пра- вильность их сборки и функционирования. Сборка на этом завершена. 2. Если все в порядке, Вставь Кабель блока питания (52) в розетку (220-240V~50-60Hz) и влючите беговую дорожку нажатием...
Seite 40
Индикация и функции: 1. Уход за беговой поверхностью: Для того, чтобы беговая дорожка на протяжении долгого времени легко и хорошо двигалась, необходимо после каждых 50 часов эксплуатации проверять беговую поверхность, которая находится на скользящей поверхности, на способность скольжения и при необходимости обрабатывать ее...
Seite 41
Описание компьютера для беговой Calories / Калории: Индикация прибл. расхода калорий в ходе тренировки в ккал № заказа 1350 (0.0 - 999 ккал.) (База 30 ккал. за км) Time / Время: Индикация продолжительности тренировки (0:00 - 99:59 Мин.) Достигая значения 99:59 мин беговая дорожка остановится автоматически.
Seite 42
упражнений. Вы находите следующие сведения о теме Упражнения на подогреве, упражнениях на растяжение мышц или общие упражнения гимнастики в нашей области загрузки под www.christopeit-sport.com Мотивация Ключевым моментом успеха программы являются регулярные тренировки. Вам следует установить конкретное время и место на...
