Power Dynamics PDD1100 Bedienungsanleitung Seite 15

TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Output channels
Output Power: RMS @ 2 Ohm / channel
Output Power: RMS @ 4 Ohm / channel
Output Power: RMS @ 8 Ohm / channel
Output Power: RMS @ 8 Ohm bridged
Input connections
Output connections
Frequency response
Crosstalk
THD
Signal to noise ratio
Input sensitivity
Power supply
Dimensions
Weight
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
Low Voltage (LVD) 2014/35/EU
•
• Electromagnetic Compatibility (EMC) 2014/30/EU
Restriction of Hazardous Substances (RoHS) 2011/65/EU
•
: 2
: 800W
: 550W
: 350W
: 1200W
: 6.3mm jack, XLR (3-pin)
: NL-4
: 20Hz - 20kHz +/- 5dB
: >700dB
: <0.02%
: >99dB
: 1.4V
: 100-240VAC 50/60Hz
: 240 x 482 x 44
: 2.75 kg
15
