InFocus LiteMount Installations-Handbuch Seite 7

3 Place the ceiling plate or pipe extension in the
ceiling so that the base box hangs down into
the room.
4 Route the projector's cables through your
ceiling and out the hole in the ceiling
(Figure
Downloaded from www.Manualslib.com
6).
Install the base box to the LiteMount False Ceiling Plate
manuals search engine
WARNING: The cables
are not rated for use in
air-handling plenums. If
the dropped ceiling is an
air-handling plenum, the
cables should be installed
within conduit.
F 2
IGURE
NOTE: When the projec-
tor is mounted on the ceil-
ing from the LiteMount
False Ceiling Plate, it
descends 12.25 inches
(31 cm) from the ceiling.
5
