4. Overview
Refer to the illustrations on page 2 of this manual.
1 voltage settings
2 current settings
3 M1 to M4
4 memory key
5 output/cut-off key
5. Operation
Press the on-off button to switch on the device.
5.1 Saving a Voltage as Preset
1. Press the memory bank (M1 to M4) button where you will be saving the desired voltage value.
2. Press the MEMORY button once. The lower display shows [EPO].
3. Set the desired voltage with the UP or DOWN button.
4. Press the memory bank button where you wanted to save the value into. The display shows [E0x] where x
is the number of the memory bank where the value was saved.
5. Press the MEMORY button again to return. The display shows [SEI].
5.2 Recalling a Stored Voltage Value
1. Make sure the lower display shows [SEI]. If not, press the memory or output button until it does.
2. Press one of the memory buttons to recall the corresponding stored value.
6.

Cleaning and Maintenance

 Disconnect the device from the mains prior to maintenance activities.
 The power supply cables must not show any damage. Have a qualified technician maintain the device.
 Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
 There are no user-serviceable parts, apart from the fuse. Contact your dealer for spare parts if necessary.
 Store the device in a dry, well-ventilated, dust-free room.
7.

Technical Specifications

input voltage ............................................................. 230 V~, 50 Hz, 12 A, 2150 W, pf 0.63
output voltage ............................................................................ 0-30 VDC adjustable max.
output current ................................................................................................... 60 A max.
ripple voltage .............................................................................................. ≤ 120 mV rms
dimensions ...................................................................................... 275 × 360 × 145 mm
weight ................................................................................................................. 4.43 kg
fuse ..................................................................................... automatic circuit-breaker C16
Use this device with original accessories only. Velleman nv cannot be held responsible in the event
of damage or injury resulting from (incorrect) use of this device. For more info concerning this
product and the latest version of this manual, please visit our website www.velleman.eu. The
information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part of this
manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise without the
prior written consent of the copyright holder.
V. 04 – 07/03/2018
LABPS3060SM
6 voltage down regulation key
7 voltage up regulation key
8 power switch
9 output positive terminal
10 output negative terminal
