REQUIRED TOOLS
AND MATERIALS:
• 2 People
• Tape Measure
• Wood Board (scrap)
• Sawhorse or Support
Table
• Hammer
• Tape
• Safety Glasses
• Phillips Screwdriver
• Scissors
• (2 each) Wrenches and/or
Socket Wrenches and Sockets
(Deep-Well Sockets are
Recommended).
3/8"
1/2"
9/16"
3/4"
AND/OR
3/8"
1/2"
9/16"
3/4"
• Extension is Recommended.
• Garden Hose or Sand
• Step Ladder - 8 ft. (2.4 m)
OPTIONAL TOOLS
AND MATERIALS:
• Large & Small Adjustable
Wrenches
© COPYRIGHT 2005 by SPALDING
Downloaded from
www.Manualslib.com
Portable System
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
manuals search engine
Owners Manual
Customer Service Center
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO
PROPERTY.
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-632 7921
Internet Address: http://www.huffysports.com
1
Write Model Number
From Box Here:
04/06
ID#
M6011141
