How to Install Replaceable Parts
REPLACING TIP AND TIP COVER
1
Find the removal tool
4
Twist the tip counter-clockwise
to remove
REPLACING THE CAP
1
Open the cap
4
Slide the cap ring onto the
pencil tube until the slit fits
securely around the notch
© 2018 Logitech, Logi and the Logitech Logo are trademarks or registered trademarks of Logitech Europe S A and/or its affiliates in the U S and other countries
2
Align the tool with the two
holes in the pencil tube
5
Insert new tip and twist
clockwise to tighten securely
2
Push the cap back, and slowly
pull the cap ring off of the
pencil tube
3
Squeeze the tool and pull off
the tip cover
6
Insert new tip cover into the
pencil tube until you hear a click
3
Slit
Notch
Align new cap to the top of
the pencil tube

English
