Lenovo TAB3 7 Plus Schnellstartanleitung Seite 5

Preparing your tablet
You can use cellular services with the WLAN + LTE model (Lenovo TB-7703X) by
inserting the Micro-SIM card provided by your carrier.
Install the Micro-SIM and microSD cards as shown.
Step 1. Insert the eject tool that comes with your device into the hole in the card tray.
Step 2. Pull out the card tray and do one of the following:
WLAN
Position a microSD card in Slot, as shown in Figure 1.
WLAN + LTE
● Position a Micro-SIM card in Slot1 and a microSD card in Slot2, as shown in
Figure 2.
● Position a Micro-SIM card in Slot1 and another Micro-SIM card in Slot2, as
shown in Figure 2.
Step 3. Carefully insert the tray with the installed cards back into the slot.
Only Micro-SIM cards work with your tablet.
Do not insert or remove the Micro-SIM card while your tablet is on. Doing so can
permanently damage your Micro-SIM card or tablet.
Figure 1: WLAN
Figure 2: WLAN + LTE
3
