1450000210_31-P4522
GB
Rechargeable LED Lantern

Specifications

The rechargeable lantern is resistant to rough conditions thanks to IP54, IK07 protection (dust, dirt, water, impact) and is therefore
suitable for car repair shops, technicians, handymen, as well as for use in the car. The lantern is fitted with a powerful 5 W SMD
LED (up to 500 lm). 1 W UV LED (395 nm) is used for easy detection of fluid leaks from car air-conditioning. The lantern's body
can be rotated by 90° and is fitted with 2 powerful magnets and an anti-slip rubber band. The lantern is also equipped with an
extendible hook which can be fully rotated 360° as well as a clip for hanging the lantern on the belt. The lantern can remain
lit continuously when fully charged for approximately 5 hours when using the SMD LED. The range for SMD LED is 30 m. The
lantern can be charged, or recharged, from a 100–240 V~, 50/60 Hz network or from a car socket with 12/24 V=. The lantern can
be used while the accumulator is recharging.
5
2
3
4
Specifications:
Light source
Accumulator pack
Network power supply
Recharging from car
Power source for car adapter, input: 12/24 V=, output: 5 V=/1 000 mA
Lantern operating temperature
Temperature for lantern charging
Lantern size
Lantern weight
Recharging the Accumulator
The lantern must be charged before first use or if the lamp does light up anymore. The lantern's accumulator must be kept
charged to prevent the voltage from dropping below the threshold level. Therefore, it is recommended to recharge the lantern
at least once every 3 months even when it is not being used. Recharging a fully discharged accumulator pack takes approx-
imately 5–6 hours (the recharge time depends on how depleted the accumulator is). Recharge the lantern in dry indoor areas.
1. Connect the network power adapter (type TEKA006-0501000EUU) to a 100–240 V~, 50/60 Hz network.
2. Turn the switch on the lantern to the off position.
3. Connect the network power adapter into the lantern's power connector – a red light will turn on on the lamp. When the
lamp (accumulator) is fully recharged, the LED will turn green.
4. After recharging, disconnect the adapter from the lantern.
The accumulator can be recharged intermittently – it has no memory effect.
148×210 mm
6
7
8
5 W (10× 0.5 W) SMD LED (500 lm) + 1 W UV LED (395 nm)
Li-Ion 18650 – 3.7 V / 4 400 mAh
type TEKA006-0501000EUU;
input: 100–240 V~ 50/60 Hz, max. 0.3 A
output: 5 V=/1 000 mA
12/24 V=
-5 °C to +45 °C
5 °C to +45 °C
38 × 56 × 211 mm
345 g (lantern + AC/DC power supply + car adapter)
1
1. 1 W UV LED (395 nm)
2. 5 W (10× 0.5 W) SMD LED
3. LED recharge indicator
4. Switch
5. Hook – 360°
6. Clip
7. Socket for charging
8. Rotary body (90°) with 2× magnets
and a rubber anti-slip band
2
