- Seite 1 UniFi nanoHD AP Recessed Ceiling Mount Model: nanoHD-RCM-3...
-
Seite 2: Package Contents
Keps Nuts (Qty. 4) (Qty. 4) (Qty. 4) Installation Requirements • UniFi nanoHD AP with Mounting Bracket (sold separately) • Phillips screwdriver • Ceiling tile mounting: Drill and 4 mm drill bit UAP-nanoHD Quick Start Guide • Refer to the... -
Seite 3: Hardware Installation
Hardware Installation 1. Remove the ceiling tile. 2. Place the Ceiling Backing Plate in the center of the ceiling tile. Mark the four mounting screw holes and the inner edge of the Ceiling Backing Plate. This opening will be used to seat the Mounting Plate. - Seite 4 4. Use the four Mounting Screws to attach the UniFi nanoHD AP’s mounting bracket to the Mounting Plate. Note: Ensure that the U logo on the mounting bracket is facing outwards when you secure it to the Mounting Plate. Locking Tab...
- Seite 5 5. Insert the four Ceiling Screws through the Mounting Plate, ceiling tile, and Ceiling Backing Plate. Hand-tighten the four Keps Nuts to fasten the screws. Then feed the Ethernet cable through the tile and bracket. IMPORTANT: We recommend that you hand-tighten the Keps Nuts to avoid compressing the ceiling tile.
- Seite 6 6. Connect the Ethernet cable to the Ethernet port on the UniFi nanoHD AP. 7. Align the Arrow on the top edge of the UniFi nanoHD AP with the Arrow on the Mounting Plate. Arrow Arrow...
- Seite 7 8. Rotate the UniFi nanoHD AP clockwise until the tabs lock into place and the Locking Tab engages. 9. Place the Mounting Cover on over the Mounting Plate. Press until it snaps into place. Note: There is a release slot on the Mounting Cover.
- Seite 8 Removal Tips • To remove the Mounting Cover from the Mounting Plate, insert a flathead screwdriver into the release slot on the Mounting Cover and lift to detach it. • To remove the AP from its mounting bracket, use a flathead screwdriver to lift the Locking Tab while turning the AP counterclockwise.
-
Seite 9: Specifications
Specifications nanoHD-RCM-3 Dimensions 210 x 210 x 20.6 mm (8.27 x 8.27 x 0.81") Weight 310 g (10.93 oz) Limited Warranty www.ubnt.com/support/warranty/ The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and, where applicable, specify arbitration instead of jury trials or class actions. -
