Transmedia-Germany HL40ML Bedienungsanleitung

Never operate the unit without a TV installed!
!
Before power connection, be sure that bracket and the TV installed correctly.
Keep the children away from power.
HL 40 ML / HL 40 MWL
: Stop Button
OK
RMT-02 remote control, 2x 7 AAA battery (not included)
Upward Movement
Press the button, the TV mount will
move upward to the lowest-profile
position against the ceiling. Press the
OK button to stop the motion.
(Tips: Clear up all obstacles
within the range of motion.)
Press the button and the mount will
automatically get to the position saved
in the corresponding button mem1.
Press the button for 1 second and you will hear a
beep, indicating that the current position
Reset Mode
If the TV mounts can't be adjusted to 0° or the max. tilting angle you previously set, press and hold the OK button for 5 seconds
and the mount will retract to the lowest-profile positon.
Reset the Tilt Range for Pitched Ceiling
The TV mount is 0° - 75° tilt adjustable by default for flat ceiling. Please reset the tilt range if you use as a pitched ceiling TV mount.
Step 1: Reset the system (Instructions on Reset Mode)
Step 2: Press
Downward Movement
Step 3: Press and hold the
Memory Setting 1 b
The unit will emit a long beep to indicate success.
Manual mode
In any positlon (but the minimum position against the ceiling): when manually push up the TV ceiling mount over a distance,
the TV ceiling mount will automatically return back to the minimum position against the ceiling.
Coding of Remote Controller and Control Box
Step 1: When the mount is powered on, press the code matching button on the mount with a thin needle or a paperclip. The unit will
emit repeatedly beeps for about 10 seconds, meanwhile press the "SET" button on the remote controller.
Step 2: Now please don't press any button or it will cause the matching process error. The process will be finished automatically until
you can't hear a beep any longer.
NOTe: The TV Mount can be matched with up to 20 remote controllers. To clean up the data of all the remote controllers, press and
hold the code matching button for 5 seconds then release. The unit will emits two beeps confirm the successful clean up and vice versa.
Hereby, Transmedia Kabelverbindungen GmbH declares that the suspension brackets type HL 40 ML / HL 40 MWL
is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following
internet address: https://www.transmedia-germany.com/downloads/download/docs/CE_HL40MxL_1912301.pdf
Recall Memory
Memory Setting 1
has been saved to memory.
,
Upward Movement
utton until the unit beeps once. Repeat this step 5 times.
and OK buttons and adjust to the proper position.
Downward Movement
Press the button, the TV mount will move
downward to the maximum tilt angle position (75° by
default). Press the OK button to stop the motion.
(Tips: Clear up all obstacles within the range of motion.)
Recall Memory
Press the button and the mount will automa-
tically get to the
position saved in the corresponding button
mem2.
Memory Setting 2
Press the button for 1 seconds and
you will hear a beep, indicating that
the current position has been saved
to memory.
