Installation - Promate MotionTorch Handbuch

Appearance & Interface Description
1. Main Light (Front Part)
2. Main Light (Back Part)
3. Screw on Base
4. LED Light
5. Time Control button
6. PIR Sensor
Operation Instructions

1.Installation

Remove all the components from the packaging but keep it for later use. Make sure that you
have the following:
• 1 x MotionTorch
• 3 x Screws
• 3 x Plastic Plugs
• 1 x User Manual
Install the batteries by taking apart the front and back main light by twisting them in an
anti-clockwise direction. Pull out the front part and open up the battery cover as illustrated.
MotionTorch
1
2
3
MotionTorch
4
5
6
