FSC BCBAL2NF Aufbauanleitung Seite 2

BCBAL2NF
ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
60 x 1109 x 2300
147.
60 x 1109 x 1953
148.
60 x 554 x 1953
149.
60 x 134 x 1663
332.
60 x 305 x 2218
334.
60 x 169 x 554
336.
32 x 690 x 1868
39.
40 x 80 x 2000
967.
40 x 60 x 1878
867.
40 (41*) x 60(41*) x 500
857.
28 x 28 x 1502
959.
Pcs. ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
60 x 1109 x 554
329.
x 3
60 x 938 x 1953
330.
x 7
60 x 305 x 1663
331.
x 2
60 x 305 x 2218
333.
x 2
60 x 169 x 554
335.
x 1
32 x 690 x 1868
40.
x 1
3 x 395 x 550
556.
x 1
40 x 80 x 850
968.
x 16
40 x 60 x 1451
957.
x 2
28 x 28 x 1725
958.
x 8
28 x 28 x 1371
960.
x 4
Pcs.
x 3
x 2
x 2
x 1
x 1
x 1
x 4
x 16
x 1
x 4
x 1
2
