General
These are the mounting instructions for the recirculation kit for the hood. Carefully read these instructions before installing
and commissioning the hood.
Important before mounting
Page 2 of these mounting instructions show the mounting drawings. Check all the articles are there as soon as they are
unpacked. The manufacturer will not accept any liability for damage caused by installation not in accordance with the
instructions or by improper installation.
INSTALLATION
Follow the mounting drawings on page 2.
Turn off the lighting and motor of the ceiling unit.
1
2
Hold the lower plate steady with two hands at the front side. Open the lower plate from the beam and tilt it down
carefully.
3
Remove both grease filters from the hood.
Place the Monoblock recirculation filter (6830055) in the opening that has been exposed. Place the Monoblock
4
recirculation filter against the protective grill in the hood. The Monoblock filter clamps onto this opening.
Return both grease filters into the hood.
5
Close the lower plate, making sure the four pins on the lower plate snap in.
6
Programming the Monoblock recirculation filter on the hood
Attention! This programming must be carried out with the motor disabled.
Programme:
Simultaneously press + and – for 5 seconds until the red LED flashes 5 times. The following functions have now been
enabled:
• The run-out time has been set to 30 minutes (instead of the default 10 minutes)
• The cleaning indicator for the Monoblock recirculation filter has been set to 200 operating hours.
• The red LED will light up after 200 operating hours. This indicates that the Monoblock recirculation filter needs clean-
ing (see the instructions below).
Reprogramming:
Simultaneously press + and – for 5 seconds. The red LED will flash 5 times for confirmation. If the programming is not
carried out, the programming is automatically set after the chimney hood has been switched on 10 times.
Inactivate the programming (the motor must have been switched on):
Simultaneously press + and the – for 5 seconds until the 3rd green LED flashes 5 times.
Clean the Monoblock recirculation filter
The Monoblock recirculation filter can be regenerated up to 12 times. This is done in the oven:
• Place the filter in the oven for 1 hour at 120°C. Provide sufficient fresh air in the room where the oven has been
placed, as smells can be released.
• Smells can be released when baking certain kinds of fish. In this case it is best to immediately regenerate the filter in
the oven.
You can find a sticker (7400049) with these instructions describing the cleaning instructions of the Monoblock Filter. You
can stick this to the inside of your hood.
Changes and misprints reserved, January 2014
EN 6
