No. Description
1
TPM Header (TPMS1)
2
CPU Fan Connector (CPU_FAN1)
3
Chassis Intrusion Header (CI1)
4
Clear CMOS Jumper (CLRCMOS1)
5
ATX Power Connector (ATXPWR1)
6
Chassis Speaker Header (SPEAKER1)
7
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
8
Chassis Fan Connector (CHA_FAN1)
9
System Panel Header (PANEL1)
10 USB 3.0 Header (USB3_0_1)
11
SATA3 Connector (SATA3_6)
12
SATA3 Connector (SATA3_5)
13
SATA3 Connector (SATA3_4)
14
SATA3 Connector (SATA3_3)
15
SATA3 Connector (SATA3_2)
16 SATA3 Connector (SATA3_1)
17
ATX 12V Power Connector (ATX12V1)
18
Front Panel Audio Header (HD_AUDIO1)
19
USB 2.0 Header (USB_45)
20 USB 2.0 Header (USB_67)
4
