SET FLASHLIGHT FC LED Gebrauchsanleitung Seite 3

Typ
Leuchtmittel
Lebensdauer Leuchtmittel
Batterien
Betriebsdauer*
Schaltmodus
Lichtstrom
Schutzart
Gewicht
Abmessungen
Artikelnummer
*durchschnittliche Leuchtdauer im Dauerbetrieb bis zu einem Lichtstrom von 3 lm
Operation
1. Before inserting / replacing the batteries, the
luminaire must be switched off. Unscrew the
luminaire body counter-clockwise and take
out the battery holder. Put the 3 AAA alkaline
batteries according to the indicated direction
into the holder. Place the holder back into the
luminaire housing and screw the luminaire
again tightly.
Attention: The luminaire does not work
when the batteries are inserted wrongly.
2. To switch it on / off, push the on / off button.
Lens
3. To adjust the light cone, hold the luminaire
body and slide the lens back and forth in order
to adjust the desired light cone.
Technische Daten
SETO FLASHLIGHT FC LED, fokussierbar
HIGH POWER LED
ca. 100.000 Stunden
3 x AAA Alkaline
Volle Leistung: ca. 3 Stunden
Geringe Leistung: ca. 12 Stunden
starkes Licht – schwaches Licht – Impulslicht
ca. 320 lm
IPX6
ca. 147 g (ohne Batterien)
Ø 34 mm x 136,5 mm
78__0G619C
Focus
Housing body
4. Multiple function (optional)
Light push of the button, when turned on,
makes the mode change possible in the order
strong light – weak light – impulse light. The
luminaire can be turned off in every mode by
pressing the button.
Closing cap
Battery holder
Warranty
With regard to warranty and guarantee regulati-
ons, the terms and conditions valid at the time of
purchase apply.
Take a look at our latest sites at www.setolite.com/en
Open
On / Off
Close
3
