Connection Diagram; Installation - PNI ST20A PLUS Benutzerhandbuch

CONNECTION DIAGRAM

AC INPUT 230V
L N
AC INPUT 230V
L N
L

INSTALLATION

• The connections are to be made according to the terminals on the switching power supply:
AC: AC input 110~230V
: Ground connection
Output +/-: Output 12V
• Ensure the stability of the connections and respect the polarity
• Use a measuring device to check the input voltage before turning on the voltage source
• Mount the source upright in a stable place
DC OUTPUT 12V -
-V -V +V +V
PNI ST20A Plus
DC OUTPUT 12V -
-V -V -V +V +V +V
AC INPUT 230V
N
PNI ST10A
DC OUTPUT 12V + AC-DC
DC OUTPUT 12V +
PNI ST3.4A
DC OUTPUT 12V - DC OUTPUT 12V +
-V +V
6
+V
ADJ
AC-DC
+V
ADJ
AC-DC
+V
ADJ
