Installation diagram
Note: The parts shown may differ from the actual scope of delivery.
Solar Irrigation System
1
Filter
2
Y-shaped four-piece coupling
3
Four-piece coupling
4
Dropper
5
Important: Place the Anti-Siphon in a place higher than the water barrel.
Hose plug
6
Anti-siphon
7
Hose (7/9 mm)
8
Hose (4/6 mm)
9
