VXL-3s Battery Expansion Kit
Stampede VXL Installation
1834
Body Clip
(not included in kit)
3627X
Battery Bar
Battery
Posts
3627X
Hold-Down
(not included in kit)
*Depending on the height of the battery used, it
may be required to place the supplied foam pad
between the battery and the ESC mount. This will
help secure the battery during vehicle operation.
Note to Stampede Owners:
This kit requires a Stampede equipped with the new hold-down
part #3627X. If your Stampede is equipped with the old hold-
down part #3627A or #3627, it will need to be replaced with part
#3627X to install this kit.
This kit will allow Traxxas Rustler VXL, Bandit VXL, and Stampede VXL to
accept batteries up to 5.4 x 1.8 x 1.67" (138 x 46 x 42.5 mm).
Traxxas, 1100 Klein Road, Plano, TX 75074, Phone: 972-265-8000, Fax: 972-265-8011, e-mail: support@Traxxas.com
3x25 BCS
1834
Body Clip
Spacers
Foam Pad*
TRAX XAS. c o m
Rustler VXL / Bandit VXL Installation
3725
ESC mount
(not included in kit)
If you have questions or need technical assistance, call Traxxas at
Battery Post Setup
Note: May not accommodate all batteries from all
manufacturers. Confirm fit before buying batteries.
1834
Body Clip
(not included in kit)
1834
Body Clip
3727A
Battery Bar
Foam Pad*
Battery
Posts
1-888-TRAXXAS
(1-888-872-9927) (U.S. residents only)
Typical 3S/ 8000+ mAh LiPo packs (Stampede)
Typical 3S/ 8000+ mAh LiPo packs (Rustler/Bandit)
Typical 2S LiPo and standard NiMH packs
Covers Part #3725X
3x25 BCS
3725
ESC mount
(not included in kit)
Spacers
KC1837-R00
Rev. 130522
