CT-TENT Clamp Operation
Safety Notes
•
•
•
•
•
•
•
•
•
•
CAUTION: The maximum load capacity for the CT-TENT is 1100 lb (500 kg). DO NOT
exceed this rating. Please check the specifications of the tent before using this clamp. The Safe
Working Load of the tent may be lower than this clamp.
DO NOT over-tighten the bolt. Too much torque can damage the bolt, damage the thread or
fracture the welding joint.
Contact
Visit
to request support or return a product.
Description
The CT-TENT by TRUSST is made of zinc-plated steel, and is rust and corrosion resistant. The CT-
TENT comes with a welded eye bolt which makes attaching a load easy, with standard rigging
hardware. It clamps onto the slots on a clear span tent Keder beam to suspend lighting, audio, truss,
and décor elements.
Overview
Installation
Installation is quick and easy, simply attach the clamp and tighten the single bolt clockwise using a
wrench until tight.
To loosen the bolt and release the clamp, remove the load and turn the bolt counter-clockwise.
5200 N.W. 108th Ave. Sunrise, FL 33351 U.S.A. +1 800-762-1084 | +1 954-577-4455 FAX | +1 954-929-5560
Use only on clear span tent Keder beam.
Carefully inspect the bracket and welding points before use.
Only trained personnel should attach the CT-TENT to tent beams.
For semi-permanent installation applications, check integrity of welds, joints and clamp tightness
weekly.
Install the CT-TENT properly; making sure the clamp is fully seated in the slots of the Keder
beam.
DO NOT use the CT-TENT for loads that exceed the maximums provided in this document.
DO NOT use the CT-TENT if it appears damaged in any way.
DO NOT use the CT-TENT if the arms, mounting plate or connecting hardware are bent.
DO NOT sideload the eye bolt of the CT-TENT clamp.
DO NOT use a CT-TENT clamp that has been dropped.
http://www.trusst.com/ for contact information. Outside the U.S., contact your distributor
Tighten/Loosen
Bolt
Clamp
Arms
At maximum 4.5 in
115 mm
Eye bolt
