1. Position the rear bracket where you want to hang the CPU wall mount and make
sure that the rear bracket is level.
2. Use the three mounting holes in the rear bracket as a template and mark the wall.
(figure 3)
figure 3
3. Orient one of the adjustable straps so that the side with the clasp and the buckle is
facing upwards. (figure 4)
figure 4
Folded end
Instruction manual
Clasp
Adjustable strap
6
Wall
Rear bracket
Buckle
