Ie Configuration - Atlantis A02-RA241-W54 Schnellstartanleitung

OS, Windows 95/98/NT/2000/Me, etc. The product provides
a very easy and user-friendly interface for configuration.
Before Configuration
This section describes the configuration required by LAN-
attached PCs that communicate with the Wireless Router
ADSL2+, either to configure the device, or for network
access. These PCs must have an Ethernet interface
installed properly, be connected to the Wireless Router
ADSL2+ either directly or through an external Switch, and
have TCP/IP installed and configured to obtain an IP
address through a DHCP server or a fixed IP address that
must be in the same subnet of the Wireless Router ADSL2+.
The default IP address of the Wireless Router ADSL2+ is
192.168.1.254 and subnet mask is 255.255.255.0. The best
and easy way is to configure the PC to get an IP address
from the Wireless Router ADSL2+ (DHCP client).
Please follow the steps below for PC's network environment
installation. First of all, please check your PC's network
components. The TCP/IP protocol stack and Ethernet
network adapter must be installed. If not, please refer to MS
Windows relative manuals.
Before you configure this Wireless ADSL Router2+, you
need to know the following default settings:
•
Username:admin
•
Password:atlantis
•
IP address (192.168.1.254), Subnet Mask
(255.255.255.0)
•
DHCP Server: enable
•
SSSID= wlan-ap, Channel=6, WEP=disable

1.6 IE Configuration

Now open IE, go to Instruments menu, select the
Connections tab and select one of the following options:
