BOX CONTENTS

•
STEREO|iO
•
USB Cable
•
Software CD
•
Quickstart Guide
•
Safety Instructions & Warranty Information booklet
FEATURES
1. PHONO INPUTS (RCA) – Connect phono-level devices,
such as turntables, to these inputs.
2. GROUNDING TERMINAL –
turntables with a grounding wire, connect the grounding
wire to these terminals. If you experience a low "hum" or
"buzz", this could mean that your turntables are not
grounded.
Note: Some turntables have a grounding wire built into
the RCA connection and, therefore, nothing needs to be
connected to the grounding terminal.
3. LINE INPUTS (RCA) – Connect line-level devices, such
as CD players, samplers or audio interfaces, to these
inputs.
4. LINE | PHONO SWITCH – Flip this switch to the
appropriate position, depending on the device connected
to the LINE and PHONO INPUTS.
phono-level turntables, set this switch to "PHONO" to
provide the additional amplification needed for phono-
level signals. If using a line-level device, such as a CD
player or sampler, set this switch to "LINE."
5. LINE OUTPUTS (RCA) – Use standard RCA cables to
connect this output to a speaker or amplifier system.
The level of this output is controlled by the VOLUME dial.
6. USB – Please use the supplied USB cable to connect
this port to an available USB port on your computer.
When plugged into your computer, the unit will draw
power from the USB connection.
7. USB LED – Illuminates when connected to your computer.
8. VOLUME – Adjusts the audio level of the LINE OUTPUTS.
If using phono-level
If you are using
1
3
2
5
4
7
6
8
