Important Information
The AP mode's default IP address is
The default Subnet Mask is
The default login name is
The default password is

LED Indicators

RS-1200
LED
Indicator
●
Power
●
Status
●
WAN1
●
WAN2
●
LAN
●
DMZ
WAN1 Port (WAN): Use this port to connect to a router, DSL modem, or
Cable modem
WAN2 Port (WAN): Use this port to connect to a router, DSL modem, or
Cable modem
LAN Port (LAN): Use this port to connect to the LAN network of the office.
DMZ: connection to the Internet (FTP, SNMP, HTTP, DNS)
Reset: Reset the Dual WAN Security Gateway to the original default
settings.
DC Power: Connect one end of the power supply to this port, the other
Dual WAN Security Gateway
RS-1200
Color ON
Green Power on
Green Ready to use
-
Green
-
Green
-
Green
Green Ready to use
192.168.1.1
255.255.255.0
admin
admin
Status
Flashing
-
Turning on
Sending/Receiving
Sending/Receiving
Sending/Receiving
Sending/Receiving

English
