for glass door locks:
WSS - Atelier F/R Business Line, Studio Privat Line
Dorma - Junior Office, Studio Rondo/Classic
Information WSS
The glass door sets were checked with the above menti-
oned locks. The lock WSS Studio Privat Line requires an
adapter rosette, which must be ordered from WSS.
Information Dorma
For the Dorma lock series Studio Rondo/Classic, with
the lever handle receptacle at the front or rear, a differ-
ent installation procedure is required. The necessary
fixing material is enclosed.
Disclaimer
HEWI does not accept any liability whatsoever for per-
sonal injuries or damage to property that is or has been
caused due to incorrect assembly, installation or use,
especially due to disregard of the listed warnings and
safety instructions.
Disposal
Proper disposal is subject to the applicable national
statutory regulations.
Lock type
Dorma Studio Rondo/Classic
„lever handle - front"
Dorma Studio Rondo/Classic
„lever handle - back"
Fixing material
2 x countersunk screws M 4 x 12 mm
1 x countersunk screw M 4 x 50 mm
1 x threaded sleeve
4 x countersunk screws M 4 x 12 mm
Montagehinweis | Mounting information
Rosette version
Remove a short cam on the rosette.
Remove the opposite long cam
(press out the threaded sleeve first).
Remove both short cams and both
long cams. (press out the threaded
sleeves first).
HEWI | 3
