Thank you for buying smarTrike,
If you have any assembly issues or are missing
a part, please call us for assistance. Our
smarTrike® assembly experts will assist you.
DO NOT RETURN TO THE STORE
If you are experiencing problems with this
product, please call our HELP LINE.
UK:
+ -
9:30am – 5:00pm Monday to Friday
www.smarTrike.com
Not Bank Holidays or weekends.
www.youtube.com/user/SmartTrikeO cial
You can also email us: help@mookie.co.uk
for assistance and advice.
675/650/695/195/690
USA: 1-855-SMTRIKE
(1-855-768-7453)
675 A
675 B
195/690
695
650
-1-
Werbung
Verwandte Anleitungen für SmarTrike Swing DLX
Inhaltszusammenfassung für SmarTrike Swing DLX
- Seite 1 Thank you for buying smarTrike, If you have any assembly issues or are missing a part, please call us for assistance. Our smarTrike® assembly experts will assist you. DO NOT RETURN TO THE STORE If you are experiencing problems with this product, please call our HELP LINE.
- Seite 2 675/650/695/195/690 665100 607130 607120 607210 607150 607220 607110 607200 607141 665140 695360 607190 675280 665160 695280 675B/695 675A 675A 195/690/650 665170 650171 695410 675B 695/195/690 650/195/690...
- Seite 3 Step 1 Parts needed to complete this section Place a washer (L), a wheel (B) and another washer (L) on the back axle. Firmly insert black plug (M) into axle opening, as shown. Align spring lock with dropout hole in axle and push firmly into position, until piece "clicks"...
- Seite 4 Step 2 Parts needed to complete this section Insert part D into part Insert part E into the C all the way through body of the trike all the the hole (as shown) the hole. way through the hole.
- Seite 5 Step 3 Parts needed to complete this section Push the apple rmly down to ly down to Push the apple firmly down to insert, insert, slightly turn until you insert, slightl slightly turn until you hear a "click". Make " sure white connector is not visible.
- Seite 6 Step 4 Parts needed to complete this section By using the Phillips screwdriver Push basket (F) firmly onto (N), remove screw by turning rear axle until it "clicks" into counter clockwise. position (see 1 & 2). Attach basket firmly to vertical frame, use removed screw and turn clockwise until secured.
- Seite 7 Step 5 Parts needed to complete this section Take the seat (G), push the screw through the By using the "Allen" key (N), remove seat hole. Screw into the most rear facing screw by turning counter clockwise. hole and firmly tighten with Allen key (N). With little force, push part H into the apple's holes until you hear a "click".
- Seite 8 Steps 6-7 Parts needed to complete this section WARNING: Ensure safety pin is inserted correctly and secured. Insert the parent handle (I) into the retaining Remove the securing pin with hole on rear of trike. Insert the pin with securing lock. safety lock.
- Seite 9 Steps 8-9 Parts needed to complete this section Max. load of basket 2.2 lb / 1 kg. Attach handles of the bag (K) to Pull the elastic bands of the bag parent handle hook. Wrap hook and around the sides of the basket. loop strap around the parent handle.
- Seite 10 Step 10 Parts needed to complete this section 675B/695 675A 675A 195/690/650 675 A Insert part P into the the safetybar. Attach hook cords, onto back seat protrusions. Insert part Q1 into the the safetybar, until you hear a "click". Slip the safety belt through the loop of the seat cover.
- Seite 11 675 A Insert part R1 into the the headrest until you hear a "click". 675 A -11-...
- Seite 12 675 B / 195 / 690 Insert part R1 into the the headrest until you hear a "click". 675B/195/690 Align part (S) into the designated holes in the center of the handlebar and push down firmly until it "clicks". -12-...
- Seite 13 Insert part R1 into the the headrest until you hear a "click". -13-...
- Seite 14 Insert part R2 into the the headrest until you hear a "click". Align part (S) into the designated holes in the center of the handlebar and push down firmly until it "clicks".
-
Seite 15: Parent Control
Parent Control 10M+ When the clutch is pulled away from the wheel there is no pedal control and the wheel is in a free-wheel position Child Control For the 24+ months stage, Push release button to place it fold up left and right footrest. back into frame. - Seite 16 When the clutch is pushed closed and aligned with the front wheel, child has pedal control. 66528057603 -16-...
