BATTERY INSTALLATION – 4 X LR03 AAA ALKALINE
(SUPPLIED)
Keypad and LCD display window
Battery position
C Button # Button
under keypad
start button
1. FIRST OPENING ON FACTORY DEFAULT CODE
Step 1 Press 'C' button
Step 2 Press factory code ' 1 2 3 4 5 6'
Step 3 Press '#' button, a melodic tone will sound and the display
confirms OPEnd
Step 4 Turn Knob or Handle clockwise and open the door while the
tone is sounding
Caution
If an incorrect code is entered, Error will appear in the display panel and a
short warning tone will sound. If an incorrect code is entered five times the
lock will cease to operate for five minutes, a warning tone will sound and
the display will indicate dELAY.
C > 1 > 2 > 3 > 4 > 5 > 6 > #
2. SETTING A NEW PERSONAL CODE.
It is advisable to set a new code with the door open and test the new code
before closing the door.
Step 1 Press '#' button
Step 2 Enter the Present Code.
Step 3 Press '#' button.
Step 4 Enter New 4~16 digit Code.
Step 5 Press '# button.
For Example:
If the present code is 1 2 3 4 5 6 and a new four digit code is decided as 4
2 4 2 press buttons as below.
# 1 2 3 4 5 6 # 4 2 4 2 #
EnTErd will be indicated in the display and a short 3 second tone will
sound to confirm the change to 4 2 4 2
# > 1 2 3 4 5 6 > # > 4 2 4 2 > #
3. SETTING THE DUAL CONTROL FUNCTION WHERE
TWO OPERATORS WITH INDIVIDUAL PERSONAL CODES
ARE REQUIRED TO OPEN THE LOCK.
With the door in the open position set the second code.
Step 1 Press the "M" memory button recessed into the back
of the door.
Step 2 Press '2' button
Step 3 Press '#' button
Step 4 Enter 2nd Personal code
Step 5 Press '#' button
EnTErd will be indicated in the display and a short 3 second tone will
sound, to confirm the 2nd code entry.
For Example:
If the present code is 4 2 4 2 and a second new four digit code is decided
as 6 7 8 9 press buttons as below. EnTErd will appear in the display
accompanied by a short tone to confirm M 2 # 6 7 8 9 #
M > 2 > # > 6 7 8 9 > #
4. TO ACTIVATE DUAL CONTROL
Step 1 Press the "M" memory button recessed into the back of the
door.
Step 2 Press '9' button
Step 3 Press '#' button
M > 9 > #
OPERATING INSTRUCTIONS FOR DS2500E
Upper Lower
Opening Battery Compartment
part part
1. Remove keypad
retaining screw
2. Press the keypad opening mark, to
release the retaining arm and swing the
keypad up and left, to open.
Phoenix Safe Company
& GUARANTEE REGISTRATION
5. TO OPERATE WITH THE DUAL CONTROL FUNCTION
Step 1 Press C button dual will appear in the display.
Step 2 Enter the first code 4 2 4 2
Step 3 Press '#' button. a short 3 second tone will sound to confirm
correct code
Step 4 Within 5 minutes enter the second code 6 7 8 9
Step 5 Press '# button. a short 3 second tone will sound to confirm
correct code and OPEnd will appear in the display and the lock
will be open. Either code can be entered first or second.
C > 4 2 4 2 > # > 6 7 8 9 > #
6. TO DEACTIVATE DUAL CONTROL
Step 1 Press the "M" memory button recessed into the back of the
door.
Step 2 Press '9' button
Step 3 Press '#' button a short 3 second tone will sound to confirm
deactivation and SinGLE will appear in the display. The second
code will be automatically erased.
M > 9 > #
7. TO HIDE CODE IN THE DISPLAY AND TURNOFF
KEYPAD SOUND.
Activate Press the "M" memory button recessed into the back of the
door, press 7 then # (HIdE appears in the display)
Deactivate Press the "M" memory button recessed into the back of the
door, press 7 then #
M > 7 > #
8. TO HIDE CODE ENTRY IN A NUMBER SEQUENCE.
The code can be disguised by inserting random numbers either before,
after or both before and after, the personal code. This procedure is
designed to increase security and to confuse a potential observer
attempting to memorise the code. This feature can be also be used
with hidden code display and silent keypad as at 7 above.
For Example
Personal code is set as 4 2 4 2 Random prefix numbers 61 Random suffix
numbers 91507
Step 1 Press C button
Step 2 Enter Code as 61 4 2 4 2 91507
Step 3 Press '#' button
The display will confirm OPEnd
C > 61 4 2 4 2 91507 > #
9. ALARM SETTING
Activate Press the "M" memory button recessed into the back of the
door, press 8 then # (ALErT appears in the display) M > 8 > #
Deactivate
Step 1 Press 'C button
Step 2 Enter Personal Code
Step 3 Press '#' button a short 3 second tone will sound to confirm
deactivation and OPEnd will appear in the display.
C > Personal Code > #
10. BATTERY LIFE: 1 YEAR 3 TIMES A DAY.
BATTERY REPLACEMENT IS REQUIRED WHEN:
1. LObAtt appears in display accompanied by a short one second warn-
ing tone.
2. Correct code is entered but lock will not open.
3. Even if batteries are completely exhausted, the codes are not lost.
11. BATTERIES
4 x 1.5 V AAA Alkaline Batteries are required to activate the lock. Used
batteries should not be disposed of with normal domestic waste. These
should be disposed of at approved collection points. You may
also return used batteries to your Retailer at their expense
(where applicable).
where peace mind is guaranteed V1/PB MAY 2018
