Renusol FS10-EW Installationsanleitung Seite 4

F S 1 0 - E W
L (max. 1720 mm)
H
Maße / Dimensions / Afmetingen
Ost-West, East-West, Est-Ouest
4/11 | Renusol FS10-EW | 12/2016
α
R
B (mm) H (mm)
950 - 1.050 240
R
α β
10° 7°
β
X
R (mm) X (mm)
2360 350
