Rodcraft RC7088 Gebrauchs - Und Wartungsanweisungen Seite 2

Air Supply Diagram
1/4 NPT
Output
Speed Power
Model
[RPM] [W]
1 2
RC7088 2800 400
3/8" (10mm)
220 mm
Air consumption
size
Free Working
[mm]
[NL/min]
3
4
11
822 312
1/2" (12mm)
Fig. 01
Fig. 02
Start
Dimension
Weight Air Inlet.
LxH
W
L
[kg] [mm] [in.]
5 6 7
1.07 220 x 43 1/4"
1/2" (12mm)
(1/2") NPT
90
0 130
(1/2") NPT
(1/2") NPT
Inner hose Sound Sound
diameter Pressure Power
[mm] [dB(A)] [dB(A)]
8 9
10 85.4
Vibrations
ahd k
[m/s ] [m/s ]
2 2
10 11 12
96.4 5.59 1.5
