Seite 2
CONTENU Enceinte Waterproof BLOOP CâbleJack 3,5 mm stéréo Câble USB / Micro-USB * * Prévu uniquement pour charger BLOOP Batterie interne intégrée...
Seite 3
CHARGEMENT Connectez le câble Micro-USB à votre enceinte et reliez le connecteur USB à votre ordinateur (ou adaptateur secteur ou voiture) La Diode reste rouge durant le chargement Une fois l’enceinte chargée, la Diode s’éteint. 3-4h pour une charge complète...
Seite 4
UTILISATION WATERPROOF BLOOP est waterproof IPX7. Vous pouvez utiliser BLOOP sous la douche ou au bord de la piscine La trappe des connecteurs doit être impérativement fermée avant immersion sous peine d’annulation de la garantie NE PAS IMMERGER BLOOP PLUS DE 30 MINUTES...
Seite 5
FONCTIONS Microphone Entrée ligne 3,5 mm Port de charge Play / Pause Connection sans ON / OFF Téléphone contact NFC Volume - Volume + Diode Pression courte : Contrôle des pistes Piste - Piste + Pression longue : Contrôle du volume...
Seite 6
CONNEXION BLUETOOTH / NFC Allumez l’enceinte par l’interrupteur ON/OFF. Recherchez le nom "BLOOP" à partir du menu Bluetooth de votre périphérique et lancez le pairage. Ou placez votre périphérique a proximité de BLOOP pour vous connecter via NFC Mot de passe : "0000" (si nécessaire).
Seite 7
UTILISATION FILAIRE Vous pouvez vous connecter à votre téléphone ou votre tablette avec le câble audio fourni. FONCTION MODULE MAINS LIBRES Lorsque vous recevez un appel, la musique se met en pause. Décrochez en appuyant sur la touche Play et parlez via le micro intégré.
INSIDE THE BOX Waterproof Speaker BLOOP Jack 3,5 mm stereo cable USB / Micro-USB cable* * Provided to charge BLOOP Internal battery...
Seite 11
Connect Micro USB cable to BLOOP and USB cable to your computer, wall adapter, or car adapter. The light turns red while charging The light turns off once BLOOP is fully charged. 3 - 4 hours for a full charge.
Seite 12
WATERPROOF USE BLOOP is IPX7 waterproof. You can use BLOOP in the shower or the pool The hatch connectors must imperatively be closed before immersion in void your warranty DO NOT IMMERSE BLOOP OVER 30 MINUTES IN DEPTH LESS THAN 1 METRE...
Seite 13
CORE FEATURES Microphone Entrée ligne 3,5 mm Port de charge Play / Pause ON / OFF Phone Touch to Beam Volume - Volume + Diode Short press : Track Control Track - Track + Long press : Volume control...
Seite 14
WIRELESS PAIRING Turn on your speaker. Open Bluetooth on your device, search “BLOOP” and pair. Or tap your device near NFC logo , and connect directly. Type : "0000" (if necessary).
Seite 15
WIRED You can also connect your device wired via included audio cable. TALK / PHONE CONTROLS When you get a call, music automatically stops. Press 1 time Play key to answer and speak With embed microphone. Press 1 time Play key to end call, music is back.
Seite 18
INHALT Lautsprecherbox BLOOP Jack 3,5 mm stereo kabel USB / Micro-USB kabel* * Provided to charge BLOOP Internal battery...
Seite 19
AUFLADEN Schließen Sie das Mikro-USB-Kabel an Ihre Lautsprecherbox an und verbinden Sie das USB-Kabel mit Ihrem Computer (oder Netz-Adapter bzw. Adapter für Zigarettenanzünder). Die Diode leuchtet während des Ladevorgangs in Rot. Sobald die Freisprecheinrichtung aufgeladen ist, leuchtet die LED aus. Bis zur vollständigen Ladung, dauert es drei bis vier Stunden.
Seite 20
BLOOP Einsatz in der Dusche oder am Pool Die Luke-Anschlüsse muss unbedingt geschlossen werden vor dem Eintauchen in Erlöschen der Garantie NICHT BLOOP über 30 Minuten IN Tiefe von weniger als 1 METER TAUCHEN MAX 30 MN / 1 M...
Seite 21
FUNKTIONEN Microphone Audio-Eingang 3,5 mm Jack USB Aufladung Play / Pause Kontaktfreier ON / OFF Anschluss NFC Phone Steuerung - Steuerung + Aktivitäts- Kurzes drücken : Steuerung titel Titel/Lautstärke - Titel/ Lange drücken : Steuerung lautstärke Lautstärke...
Seite 22
BLUETOOTH-/NFC-NUTZUNG Schalten Sie Ihre Lautsprecherbox über den ON/OFF-Schalter ein. Suchen Sie den Namen „BLOOP“ aus dem Bluetooth-Menü Ihres Peripheriegerätes und starten Sie Nähe des BLOOP, um sich über NFC zu verbinden. Passwort: „0000“ (falls erforderlich).
KABELGEBUNDENE NUTZUNG Sie können auch Ihr Telefon oder Ihr Tablet mit demim Lieferumfang enthaltenen Audio-Kabel anschließen. FREISPRECH-MODUL-FUNKTION Bei einem eingehenden Anruf pausiert die Musik. Heben Sie ab, indem Sie die Bluetooth-Taste drücken und sprechen Sie über das integrierte Mikrofon. Drücken Sie die Bluetooth-Taste erneut, um aufzulegen und die Musik weiterlaufen zu lassen.
USB al ordenador (oa un adaptador de corriente o para el coche) La luz permanecerá en rojo mientras dure la carga Una vez cargada BLOOP, las luces se apagan Plena carga: 3 - 4 horas.
Seite 28
USO WATERPROOF BLOOP es resistente al agua IPX7. Puede BLOOP uso en la ducha o la piscina Los conectores de sombreado debe imperativamente ser cerrada antes de la inmersión en anular la garantía NO SUMERJA BLOOP más de 30 minutos EN...
Seite 29
FUNCIONES Microfono Entrada de audio Jack 3,5mm Carga USB Play / Pause ON / OFF Conexión Phone Pistas - Pistas + Pulsación corta : Pistas control Volumen - Volumen + Conexión Pulsación larga : Volumen control...
Seite 30
UTILIZACIÓN BLUETOOTH/NFC Enciende el altavoz pulsando el interruptor ON/OFF Busca el nombre "BLOOP" en el menú Bluetooth de tu periférico e inicia el emparejamiento o coloca tu periférico cerca del BLOOP para conectarte por NFC Contraseña: "0000" (sise te pide)
Seite 31
UTILIZACIÓN CON CABLE También podrás conectar el altavoz a tu teléfono o tableta gracias al cable incluido FUNCIÓN KIT MANOS LIBRES Cuando recibas una llamada, la música se pondrá en pausa. Descuelga pulsando el botónBluetooth y habla a través del micrófono integrado Presiona el botón Bluetooth para colgar y reanudar la reproducción musical...
Seite 34
CONTENUTO Altoparlante BLOOP Jack 3,5 mm stéréo cavo USB / Micro-USB cavo* * Provided to charge BLOOP Internal battery...
Seite 35
CARICAMENTO DELL'ALTOPARLANTE Collegare il cavo Micro-USB all'altoparlante e il connettore USB al computer (o all'adattatore CA o all'auto) Il LED rimane rosso durante la carica Una volta caricato Bloop, le luci si spengono A pieno carico: 3-4 ore.
Seite 36
USO WATERPROOF BLOOP è impermeabile IPX7. è possibile uso BLOOP sotto la doccia o in piscina I connettori tratteggio deve imperativamente essere chiuso prima dell'immersione in invalidare la garanzia NON IMMERGERE BLOOP oltre 30 minuti nella profondità inferiore a 1 METRO...
Seite 37
FUNZIONI Microfono Ingresso audio 3,5 mm Jack Ricarica USB Play / Pause ON / OFF Connessione Phone Tracce - Tracce + Premere breve : Tracce controllo Volume - Volume + Premere a lungo : Volume controllo...
Seite 38
UTILIZZO BLUETOOTH/NFC Accendere l'altoparlante con l'interruttore ON/OFF Cercare il nome "BLOOP" nel menu Bluetooth del dispositivo ed eseguire l'associazione, oppure posizionare il dispositivo in prossimità di BLOOP per connettersi tramite NFC Password: "0000" (se richiesta)
Seite 39
UTILIZZO WIRED È, inoltre, possibile collegare il telefono o il tablet con il cavo audio in dotazione FUNZIONE MODULO VIVAVOCE Quando si riceve una chiamata, la riproduzione musicale verrà messa in pausa. Per rispondere alla chiamata, premere il pulsante Bluetooth e parlare attraverso il microfono integrato Premere il pulsante Bluetooth per riagganciare e riavviare la riproduzione musicale...
Seite 42
INHOUD Spreker BLOOP Jack 3,5 mm stereo kabel USB / Micro-USB kabel* * Provided to charge BLOOP Internal battery...
Seite 43
OPLADEN Sluit de micro USB kabel opuw koptelefoon aan en verbindhet USB-eind met uw computer (of met uw oplader of auto). Het rode LED-lampjebrandt tijdens het laden. Bloop Indien volledig opgeladen, het licht uit is. Volledige oplaadtijd 3-4 uur.
Seite 44
WATERPROOF GEBRUIK BLOOP is IPX7 waterdicht. je kunt BLOOP gebruik in de douche of het zwembad Het luik connectors moet verplicht worden afgesloten vóór onderdompeling in vervalt de garantie Dompel BLOOP OVER 30 MINUTEN IN DIEPTE MINDER DAN 1 METER...
GEAVANCEERDE FUNCTIES Microfoon Jack Plug 3,5 mm Jack USB Oplader Play / Pause ON / OFF Phone Spoor - Spoor + Kort indrukken : Spoor instellen Volume - Volume + Lang indrukken : Volumeregelaar...
Seite 46
VERBINDING MAKEN MET BLUETOOTH / NFC Ligue a coluna através do interrutor ON/OFF. Zoek de naam “BLOOP” op in het Bluetooth menu van uw Bluetooth-apparaat om een draadloze verbinding tot stand te brengen. Of plaats uw Bluetooth-apparaat in de buurt van BLOOP om via NFC een verbinding te maken.
Seite 47
GEBRUIK MET DRAAD Met de meegeleverde audio kabel is het eveneens mogelijk om een verbinding temaken met uw tablet of telefoon. HANDSFREE FUNCTIE Wanneer u een oproep krijgt, muziek stopt automatisch. Druk op Play-toets 1 tijd om te antwoorden en spreken Met embed microfoon.
