Behringer VINTAGE PHASER VP1 Bedienungsanleitung

Thank you for showing your confidence in us by purchasing the BEHRINGER VINTAGE PHASER VP1. This
high-quality effect pedal is designed for all musicians who want to their sound some extra pep. Thanks to its
high-performance features you get authentic and classic three dimensional phase shifting—from rapid rotary speaker
to impressive jet plane effects.
With the phaser, a second, phase-shifted signal is added to the original audio signal. The resulting sound is thicker
and above all livelier. This effect is often used for guitar sounds and keyboards. In the ’70s, it was also extensively
used for other instruments like electric pianos.
The RATE control determines the speed of the phase shifting effect.
The TONE switch lets you chose between negative feedback (lower position) or positive feedback (upper
position) phaser modes. Negative feedback means that the delayed signal is inverted before it is fed back to the
original signal. In positive feedback mode the delayed signal is not inverted. In this case the effect has a more
detuned character enabling to use the unit as vibrato effect for example.
The STATUS LED illuminates when the effect is activated.
Use the footswitch to activate/deactivate the effect.
Use this 1/4" TS INPUT connector to plug in the instrument cable.
The 1/4" TS OUTPUT connector sends the signal to your amp.
Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located on the bottom. Open the lid to install or replace the 9 V battery.
+
The VP1 has no on/off switch. As soon as you insert the jack into the IN connector, the VP1 begins
running. When not using the VP1, remove the jack from the IN connector. This extends the life of
the battery.
The SERIAL NUMBER is located on the bottom.
For our current warranty terms, please refer to our website at http://www.behringer.com.
VINTAGE PHASER VP1
1. CONTROLS
Top view
2. WARRANTY
