TP140 Forest See Saw IN5002-E 12 14:TP140 Forest See Saw IN5002-E 12 14 10/12/2014 14:16 Page 7
3
M8
washer
4 MW1020
Handle upright
x2
MW1019
M6 x 20mm
M6 Nyloc
washer
locknut
MT4110
PM2009
Pivot bush
x2
x2
Main beam
Pivot bush
ASSEMBLY TIP
Do not tighten bolts before seat has
been attached in Stage 6.
1
Gyro centre tube
M8 Nylon Insert
Dome Nut
FA8163
M8
M8 Nyloc
washer
locknut
x4
M6 x 120mm
FA4552
M6 x 20mm
M6 Nyloc
washer
locknut
Pivot bush
M6 x 120mm
7
x1
M8 x 75mm
FA6209
M8 PM2014
Washer
Gyro clamp
FA9766
x1 x2
M6 Nylon Insert M6 x 20mm
Dome Nut Washer
FA5095
FA5192
x4 x4
M6 x 120mm
Forest Wooden Seesaw
x2
