Section 1 - Product Overview
1 LED
2 WPS Button
3 Reset Button
D-Link DCH-S165 User Manual
Hardware Overview

Side and Bottom

Solid Green
Blinking Green (slow)
Blinking Orange (continuous)
Solid Red
Blinking Red
Light Off
Pressing the WPS button for 1 second allows you to connect with Wi-Fi clients using Wi-Fi Protected Setup.
Pressing the reset button for 10 seconds will reset the DCH-S165 to the factory default settings.
1
2
3
The device is connected to the network.
WPS is working.
The device is not connected to the network.
• The device is powering on.
• The firmware is being upgraded.
• The device is defective.
The device is in recovery mode.
The device is powered off.
