Quickstart Guide
WiPry 2500
W A R N I N G
DO NOT APPLY
MORE THAN 20DBM TO
More on
2500O
THE ANTENNA WITH
EXTERNAL ATTENUATION
CONNECT TO HOST DEVICE
Android, Google Play and the Google Play logo are trademarks of Google Inc. iPad, iPhone, and iPod touch are trademarks of Apple Inc, registered in the U.S. and other countries. iPad Air, iPad mini, and Lightning are trademarks of Apple Inc.
ACCESSORY
UT
1. Screw RP-SMA antenna into the appropriate port.
2. Download "WiPry" in either the App Store or on Google Play.
PC & Mac versions are available at oscium.com/quickstart
3. Insert cable into both the accessory and the host device.
4. When the software is connected to the WiPry 2500x hardware,
a red light will illuminate near the antenna connector.
5. Attach velcro to the backs of both the accessory and the
host device.
6. Insert batteries for all iOS devices. After use, disconnect host device.
Insert charge cable for overnight charge (four hours = full charge).
Batteries can also be replaced for immediate results.
***Batteries required to enable SSID's on iOS, PC, Mac.***
ANTENNA
CHARGE
