01845
Accoppiatore di linea, installazione su guida EN 50022, occu-
pa 3 moduli da 17,5 mm - grigio RAL 7035.
Il dispositivo permette il passaggio dei seguenti messaggi:
• messaggi di gruppo il cui indirizzo destinazione è presente nella tabella del dispo-
sitivo oppure indirizzi di gruppo predefiniti per garantire l'intercambiabilità con il
Sistema Antintrusione Via Bus e il funzionamento degli scenari tipo "Riservato";
- tutti i messaggi broadcast;
- tutti i messaggi punto-punto (l'indirizzo destinazione è un indirizzo fisico) per i
quali il passaggio del messaggio ha senso. L'indirizzo fisico di un dispositivo è
legato alla topologia dell'impianto. I dispositivi appartenenti a una linea possono
avere solo certi valori di indirizzo fisico; l'accoppiatore è in grado di decidere, in
base al valore di detto indirizzo, se il messaggio deve passare da una linea all'altra
o essere bloccato.
CARATTERISTICHE.
• Tensione nominale di alimentazione: BUS 29 V
Nota: il dispositivo deve essere alimentato da entrambi i lati.
• Consumo: 10 mA
• 3 moduli da 17,5 mm
CONFIGURAZIONE.
PER LE OPERAZIONI DI INSTALLAZIONE E CONFIGURAZIONE, VEDERE IL
MANUALE ISTRUZIONI DEL SISTEMA By-me ALLEGATO ALLA CENTRALE
DI CONTROLLO.
• Il dispositivo deve essere configurato utilizzando il menu di configurazione dedi-
cato alle interfacce della centrale.
• Blocchi funzionali: 1
• Selezione del blocco funzionale (configurazione): durante la configurazione, quan-
do la centrale richiede di premere il pulsante dei dispositivi:
- premere il pulsante di configurazione, si accende il led rosso;
- a led rosso acceso la centrale configura il blocco funzionale; al termine dell'ope-
razione il led rosso si spegne.
PARAMETRI.
Tramite la centrale è possibile aggiungere o eliminare indirizzi di gruppo.
REGOLE DI INSTALLAZIONE.
L'installazione deve essere effettuata con l'osservanza delle disposizioni regolanti l'in-
stallazione del materiale elettrico in vigore nel paese dove i prodotti sono installati. Per
ulteriori istruzioni si faccia riferimento al manuale in allegato alla centrale di controllo.
CONFORMITÀ NORMATIVA.
Direttiva EMC
Norma EN 50428
Viale Vicenza, 14 - I 36063 Marostica VI
Tel. +39 0424 488 600 - Fax (Italia) +39 0424 488 188 - Fax (Export) +39 0424 488 709
www.vimar.eu
Line coupler, installation on EN 50022 rails, occupies 3 mod-
ules of 17.5 mm - grey RAL 7035.
The device allows the following message to pass through:
• group messages whose destination address is in the device table or predefined
group addresses in order to ensure interchangeability with the Burglar Alarm
System Via BUS and "Reserved" scenario operation;
- all broadcast messages;
- all point-to-point messages (the destination address is a physical address) for
which the passage of the message is meaningful. The physical address of a
device is tied to the system's topology. The devices belonging to a line can have
only certain physical address values; the coupler is able to decide whether the
message must pass from one line to the other or be blocked, depending on the
value of the address.
CHARACTERISTICS.
• Rated supply voltage: BUS 29 V
Note: The device must be powered on both sides.
• Consumption: 10 mA
• 3 modules of 17.5 mm
CONFIGURATION.
FOR THE OPERATIONS OF INSTALLATION AND CONFIGURATION, SEE THE
By-me SYSTEM INSTRUCTIONS MANUAL ATTACHED TO THE CONTROL
UNIT.
• The device must be configured using the configuration menu dedicated to the
control unit interfaces.
• Functional blocks: 1
• Selecting the functional block (configuration): during configuration, when the
control unit requires pressing the device button:
- press the configuration button, the red LED will light up;
- with the red LED on, the control unit will configure the functional block; at the end
of this operation the red LED will go out.
PARAMETERS.
By using the control unit it is possible to add or delete group addresses.
INSTALLATION RULES.
Installation should be carried out observing current installation regulations for electri-
cal systems in the country where the products are installed. For further instructions,
please see the manual attached to the control panel.
CONFORMITY.
EMC directive
Standard EN 50428
Istruzioni
Instruction sheet
49400305A0 01 1010
VIMAR - Marostica - Italy
