CONNECT TO AUDIO SOURCE
1A For 3 5 mm connection:
Connect one end of the provided 3 5 mm cable to the corresponding jack on the back of subwoofer or
the 3 5 mm jack on the control pod Insert the other end of the 3 5 mm cable into the audio jack on your device
(computer, smartphone, tablet, etc )
1B For RCA connection:
Connect one end of the RCA cable to the corresponding RCA jack on the back of subwoofer Insert the other end
of the RCA cable into the RCA outlet on your device (TV, gaming console, etc )
Note: The RCA cable is not included in the box and must be purchased separately
2 Plug your headphones into the headphone jack on the control pod Adjust the volume either from the control pod
or the audio source
3 Power speakers on/off by turning clockwise the volume knob on the control pod You will notice a "click" sound once
the system is ON (the LED in front of the wired remote will also turn on)
1A
IN
OUT
2
1B
3
ON / OFF
VOL
IN
OUT
Click
ON
English 5
