Package Contents
Packungsinhalt
del paquete
Device
4 x M2*4 flat head screws for device
(2 x screws for spare parts)
Note: Please use the included screws to secure the device.
2
Device Information
Geräteinformationen
Información del dispositivo
Front View
MB511SPO-B
(for 12.7mm height Slim ODD )
1
2
MB511SPO-1B
(for 9.5mm height Ultra Slim ODD)
1. LED Indicator (Power: Solid blue light; HDD access: Blinking blue light)
2. EZ-Lock Drive Ejection Button
3. Power Switch
Contenu
Contenido
包裝說明
包装说明
User manual
Key × 2
Informations dispositif
本体説明
機體說明
机体说明
3
Rear View
3
Installation Guide
Installationsanleitung
de instalación
製品の組み込み手順について
1. Installing 2.5" Drives - Insert the drive all the way into the slot.
Note: Please align the drive
and device connector before
inserting the drive.
2. Removing 2.5" Drives - Unlock the EZ-Lock drive ejection button and then
firmly move the EZ-Lock drive ejection button to the left, and then push the
ejection button to eject the drive.
Step-1
Push button
to left side
Step-2
Push button in to eject drive
6 Pin SATA
7 Pin SATA
Guide d'Installation Guía
操作步驟
操作步骤
Unlocked
Locked
The EZ-lock drive ejection
button will pop out after
inserting the drive.
