OmniScaler digitaler Eingang
46 GND (shield, return
for +5V)
47
48
49 GND
50
51
52 GND
53
54 GND
55
56
57 GND
58
59
60 GND
Barco – Argus Workstation für Windows – DOC-3266-0 – Ausgabe 06 – April 2004
45 1 - Data1+
44 1 - Data1-
43 1 - Clock+
42 1 - Clock-
41
40 1 - Hot Plug detect
39 1 - LED PGA
38 Scaler detect
37 0 - LED PGA
36 0 - Hot Plug detect
35
34 0 - Clock-
33 0 - Clock+
32 0 - Data1-
31 0 - Data1+
16 1 - Data0+
17 1 - Data0-
18 1 - Data2+
19 1 - Data2-
20
21
22
23 Int Scaler
24
25
26
27 0 - Data2-
28 0 - Data2+
29 0 - Data0-
30 0 - Data0+
_________________________________________________________________________
7. Technischer Anhang
15 GND
14
13
12 GND
11
10 1 - DDC clock
9 1 - DDC data
8 GND
7 0 - DDC data
6 0 - DDC clock
5
4 GND
3
2
1 GND
Tabelle 7-13
Dual-DVI Stecker - digitaler Eingang
